Kubota MD107

Last Updated: June 2024

Overview

The Kubota MD107 is a utility tractor that was manufactured between 1995 and 2001. It is a robust 4x4 tractor equipped with the Kubota F5802 engine, which is a liquid-cooled, 5-cylinder diesel engine with an engine displacement of 355.9 cubic inches. The engine is capable of delivering 105.5 horsepower at 2400 RPM. Transmission is a 24-speed partial power shift, providing ample gearing for various tasks. With a wheelbase of 101 inches, the tractor has an overall length of 165.8 inches, a width of 80.3 inches, and a height of 106.1 inches. It weighs in at 8510 lbs, indicating a substantially built machine that can handle significant workloads. Standard tire sizing is given as Front: 13.6-24 and Rear: 16.9-38, indicating it's outfitted with agricultural tires suitable for a range of fieldwork. The Kubota MD107 is a solid choice for a variety of utility applications in agriculture, particularly for those in need of a capacious and powerful tractor.
Show more...

Key Specifications

Category: Utility

Power Output: 105.5

Transmission: Partial Power Shift

Drive Type: MFWD (4WD)

Operating Weight: 8510

Fuel Type: Diesel

Kubota MD107 vs. Similar Tractors

Power Output
Above Average
Greater than 84% of similar tractors.
Operating Weight
Average
Greater than 58% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
F5802
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
5
Displacement (ci)
355.9
Bore (in)
4.29
Stroke (in)
4.92
Rated RPM
2400
Power Output (hp)
105.5

Transmission

Type
Partial Power Shift
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
165.8
Width (in)
80.3
Height (in)
106.1
Operating Weight (lb)
8510

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (4WD)
Steering Type
-
Coolant Capacity (qts)
15.2
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2001
Hitch Type
-
Hitch Category
II
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
