Kubota M96SDSC

Last Updated: June 2024

Overview

The Kubota M96SDSC is a utility tractor powered by a 95 hp V3800-DI-T engine from Kubota, indicating robust performance capacity for various agricultural tasks. This model's engine is a 4-cylinder diesel power unit turbocharged and able to deliver 84 hp PTO power, ensuring strong mechanical proficiency for attachments and implements. With a full range of 32 forward and reverse fully synchronized gears, operators can choose the optimal speed for a variety of chores or terrains. Robustly built, it has an operating weight of 8024.9 lbs and is capable of turning around in a 15.5-ft radius which enhances maneuverability in confined spaces. The standard three-point hitch on this model is a Category II, with a notable lift capacity of 4629.8 lbs. The utility and flexibility of the M96SDSC make it a workhorse for tasks demanding precision and power. Missing information such as chassis configurations and steering type do not detract from the tractor's known functions. The unconfirmed front and rear tire sizes are essential for spec comparisons, but the tractor's tire type has been identified as cast, which could reference cast wheels.
Show more...

Key Specifications

Category: Utility

Power Output: 95

Transmission: Fully synchronized

Operating Weight: 8024.9

Fuel Type: Diesel (assumed based on the engine model)

Lift Capacity: 4629.8

Kubota M96SDSC vs. Similar Tractors

Power Output
Above Average
Greater than 80% of similar tractors.
Hitch Capacity
Above Average
Greater than 74% of similar tractors.
Operating Weight
Average
Greater than 56% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3800-DI-T
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel (assumed based on the engine model)
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
230
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
95

Transmission

Type
Fully synchronized
Forward Gears
32
Reverse Gears
32
Total Gears
-

Dimensions

Length (in)
13.6 (likely a typo, should probably be closer to 163.2" assuming the value should have been ft, not in)
Width (in)
91.2
Height (in)
104.4
Operating Weight (lb)
8024.9

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Cast
Manufacture - End Year
-
Hitch Type
Cat II
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
4629.8
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
