Kubota M90A

Last Updated: June 2024

Overview

The Kubota M90A is a utility tractor produced between 2009 and 2013, designed to cater to a variety of tasks in the agricultural sector. It comes equipped with a 4-wheel drive chassis and power steering, making it suitable for a range of terrains and applications. The core of this machine is its powerful Kubota V3800-T turbocharged diesel engine with a displacement of 230 cubic inches, producing 88.8 horsepower at 2600 RPM. This is combined with a power shift transmission, offering 16 forward and a total of 40 gears for unmatched field adaptability and operation. Physical dimensions reveal a length of 168.1 inches, width of 72.6 inches, and height of 103.2 inches, with a substantial operating weight of 7782 lbs. While detailed information about features such as the hitch lift capacity and hydraulic system type is not specified, the robust construction and engineered ergonomics of the Kubota M90A assert its position as a reliable tractor in its category.
Show more...

Key Specifications

Category: Utility

Power Output: 88.8

Transmission: Power Shift

Drive Type: 4WD

Operating Weight: 7782

Fuel Type: Diesel

Kubota M90A vs. Similar Tractors

Power Output
Above Average
Greater than 75% of similar tractors.
Operating Weight
Average
Greater than 56% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3800-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
230
Bore (in)
3.94
Stroke (in)
4.72
Rated RPM
2600
Power Output (hp)
88.8

Transmission

Type
Power Shift
Forward Gears
16
Reverse Gears
-
Total Gears
40

Dimensions

Length (in)
168.1
Width (in)
72.6
Height (in)
103.2
Operating Weight (lb)
7782

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2013
Hitch Type
II
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
