Kubota M8200 Narrow ROPS

The Kubota M8200 Narrow ROPS is designed to cater to the unique needs of specialty farming. It features a Kubota V3300-TE turbocharged diesel engine with Electronic-TVCS (Three Vortex Combustion System), providing a liquid-cooled environment and rated at 82 horsepower with a peak rated RPM of 2600. Its engine displacement is 202 cubic inches across four cylinders, contributing to its robust performance. The fully synchronized transmission system offers 12 forward and reverse gears, which give the tractor a high level of efficiency in field operations. Despite being categorized with a Narrow ROPS for specialty tasks, this tractor has a balance of agility and power with features like a Category I with Category II link ends hitch system and a notable lifting capacity of 3307 pounds. This tractor operates on a 12V electrical system, boasts a hydraulic pump flow capacity of 17.1 gal/min, and rolls on radial tires designed for nearly any field condition. With a wheelbase of 6.6 feet and a tight turning radius of 10.5 feet, it provides exceptional maneuverability. However, the exact dimensions of the front and rear tires are not specified beyond the radial tire type and their sizes of 8.0-16R1 front and 12.4R24 rear. Moreover, the tractor's operating weight has been listed at 4078.6 pounds, creating some confusion since an alternate weight of 4740 pounds is also available, posing potential discrepancies in the provided data. The physical dimensions of the tractor—11.2 inches long, 40.8 inches wide, and 90 inches tall—further confirm its suitability for narrow or confined spaces, typical for orchard or vineyard use. Without available data, several specifications such as engine bore, stroke, and specific fuel type remain unknown.
