Kubota M7133

Last Updated: June 2024

Overview

The Kubota M7133 is categorized as a utility tractor that offers versatility for a range of tasks found on a farm, in landscaping, or on construction sites. It is equipped with a 4x4 MFWD 4WD chassis, ensuring powerful traction and maneuverability across diverse terrains. The tractor is powered by Kubota's V6108 engine, which is a liquid-cooled, four-cylinder diesel engine, boasting a power output of 130 horsepower according to ECE R120 standards, with a peak of 150 horsepower. This engine features a turbocharged intercooled system and utilizes advanced technology with a 16-valve configuration for efficient fuel combustion and performance. With a starting year of manufacture in 2020, the M7133 is part of the contemporary M7003 Series, ensuring it incorporates modern technology and conveniences. The tractor's physical dimensions provide significant stability during operations, given its length of 187.7 inches, width of 98.4 inches, and height of 119.3 inches. The weight of over 16,000 lbs further demonstrates its substantial and robust nature for heavy-duty tasks. Considering its features, the Kubota M7133 is well-suited for heavy agricultural work requiring power, precision, and reliability.
Show more...

Key Specifications

Category: Utility

Power Output: 130 ECE R120 / 150 ECE R120 maximum

Transmission: Six-speed power shift / Infinitely variable transmission (IVT)

Drive Type: 4WD

Operating Weight: 16204

Fuel Type: Diesel

Kubota M7133 vs. Similar Tractors

Power Output
Excellent
Greater than 100% of similar tractors.
Operating Weight
Average
Greater than 68% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V6108
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
16-valve
Fuel Type
Diesel
Induction Type
Turbocharged intercooled
Cylinders
4
Displacement (ci)
373.7
Bore (in)
4.65
Stroke (in)
5.51
Rated RPM
1900
Power Output (hp)
130 ECE R120 / 150 ECE R120 maximum

Transmission

Type
Six-speed power shift / Infinitely variable transmission (IVT)
Forward Gears
30
Reverse Gears
15
Total Gears
-

Dimensions

Length (in)
187.7
Width (in)
98.4
Height (in)
119.3
Operating Weight (lb)
16204

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
-
Hitch Category
III
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open center
