Kubota M7060HDRC12

Last Updated: June 2024

Overview

The Kubota M7060HDRC12 is a utility tractor often used for various types of agricultural work. It comes with a Kubota V3307-CR-TE4 four-cylinder turbocharged engine that provides a power output of 71 horsepower at a rated RPM of 2400. The PTO power is rated at 64 hp. It features a 12-speed HD12 transmission with equal numbers of forward and reverse gears, enabling versatile maneuverability and control during operations. The tractor is built with a sturdy three-point hitch capable of lifting 3307 lbs and is equipped with a hydraulic wet disc brake system for reliable stopping power. The operating weight of the tractor is approximately 5026.6 pounds, reflecting its substantial built quality and robustness. The M7060HDRC12 began production in 2015, and the end year of manufacture is not specified.
Show more...

Key Specifications

Category: Utility

Power Output: 71

Transmission: HD12

Operating Weight: 5026.6

Lift Capacity: 3307 lbs

Kubota M7060HDRC12 vs. Similar Tractors

Power Output
Average
Greater than 65% of similar tractors.
Hitch Capacity
Average
Greater than 60% of similar tractors.
Operating Weight
Average
Greater than 43% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3307-CR-TE4
Cooling Type
-
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
-
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
203
Bore (in)
-
Stroke (in)
-
Rated RPM
2400
Power Output (hp)
71

Transmission

Type
HD12
Forward Gears
12
Reverse Gears
12
Total Gears
-

Dimensions

Length (in)
138
Width (in)
74.4 (6.2 ft converted to inches)
Height (in)
-
Operating Weight (lb)
5026.6

Power Take-Off (PTO)

PTO Type
Live -independent PTO, electro-hydraulic clutch with brake
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
3307 lbs
Operator Station Type
Cab (implied by the presence of cab height)
Starter Type
-
Brake Type
Hydraulic wet disc
Hydraulic System Type
-
