Kubota M7-131P-KVT

Last Updated: June 2024

Overview

The Kubota M7-131P-KVT is a versatile utility tractor equipped with a four-cylinder Kubota V6108-CR-TIEF4 diesel engine that produces 128 horsepower with a maximum torque of 433.7 lbs/ft at 1400 rpm. The engine features a turbocharger with an intercooler and direct injection technology, and it operates at rated speeds of up to 2200 rpm. The tractor's displacement is 374 cubic inches, with a bore of 4.7 inches and a stroke of 5.6 inches, emphasizing its robust and efficient design for demanding agricultural tasks. Hydraulic operations are made smooth with a pump flow capacity of 29.1 gallons per minute and system pressure standing at 2900.8 psi. This model carries a notable lift capacity of nearly 11800 pounds on its category 3 rear hitch and offers multiple PTO speeds, indicating its suitability for various implements. The tractor's operating weight is 15097.3 pounds and it can achieve speeds up to 25 mph. Fitted with hydraulically operated wet disc brakes and substantial tire sizes—14.9R28 front and 18.4R38 rear—it provides durability and traction in diverse conditions. The Kubota M7-131P-KVT is designed to meet the needs of modern agriculture, offering an efficient and powerful engine, sophisticated hydraulics, and a comfortable operating environment.
Show more...

Key Specifications

Category: Utility

Power Output: 128

Transmission: KVT (Kubota Variable Transmission)

Operating Weight: 15097.3

Fuel Type: Diesel

Lift Capacity: 11794.8

Kubota M7-131P-KVT vs. Similar Tractors

Power Output
Above Average
Greater than 89% of similar tractors.
Hitch Capacity
Above Average
Greater than 87% of similar tractors.
Operating Weight
Average
Greater than 68% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V6108-CR-TIEF4
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged with intercooler
Cylinders
4
Displacement (ci)
374
Bore (in)
4.7
Stroke (in)
5.6
Rated RPM
2200
Power Output (hp)
128

Transmission

Type
KVT (Kubota Variable Transmission)
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
187.8
Width (in)
110.4
Height (in)
120
Operating Weight (lb)
15097.3

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
1000
PTO Speed 2 (rpm)
540
PTO Speed 3 (rpm)
1000E

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
25.36
Front Tire Diameter (in)
28
Front Tire Width (in)
-
Rear Tire Diameter (in)
38
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
-
Hitch Type
Category 3/3N
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
11794.8
Operator Station Type
-
Starter Type
-
Brake Type
Hydraulically operated wet disc
Hydraulic System Type
Electronic draft control
