Kubota M5N-091HDRC24

Last Updated: June 2024

Overview

The Kubota M5N-091HDRC24 is a turbocharged utility tractor that comes with a direct injection, water-cooled 4-cycle diesel engine made by Kubota. Marked by its model V-3800-CR-TIER4, this engine delivers 95 horsepower at a rated RPM of 2600, and a PTO power of 58.1 hp. It features a total of 24 forward gears and reverse gears, which indicates a highly versatile transmission system likely adaptable to various tasks. With an operating weight of 5621.8 lbs and front tires sized at 8-16 and rear tires at 12.4-24, this tractor is designed to handle substantial farm workloads. The three-point hitch capacity of 3307 lbs at 24 inches combined with its rigid lower link and easy adjust stabilizers classify it as a Category II hitch, underscoring its capability to work with a range of implements. Further equipped with a pair of remote control valves and pump flow capacity signaling strong hydraulic functionality, this model is purposed for demanding agricultural operations. While some specifications such as chassis, drive type, and starter type remain unspecified, this tractor's existing features portray it as a dependable and efficient machine for a variety of tasks in farming and land management.
Show more...

Key Specifications

Category: Utility

Power Output: 95

Operating Weight: 5621.8

Fuel Type: Diesel

Lift Capacity: 3307

Kubota M5N-091HDRC24 vs. Similar Tractors

Power Output
Above Average
Greater than 80% of similar tractors.
Hitch Capacity
Average
Greater than 60% of similar tractors.
Operating Weight
Average
Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V-3800-CR-TIER4
Cooling Type
Water-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
-
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
95

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
-

Dimensions

Length (in)
-
Width (in)
49.2
Height (in)
91.2
Operating Weight (lb)
5621.8

Power Take-Off (PTO)

PTO Type
Electro-hydraulic
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
16
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Rigid lower link, easy adjust stabilizers
Hitch Category
II
Hitch Position
-
Hitch Capacity (lb)
3307
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
