Kubota M5N-091HDCC24

Last Updated: June 2024

Overview

The Kubota M5N-091HDCC24 is a tractor powered by a water-cooled, turbocharged, four-cylinder Kubota V-3800-CR-TIER4 diesel engine, with an engine power output of 95 hp at 2600 rpm and PTO power of 58.1 hp. This tractor has a high number of gears, with 24 forward and 24 reverse gears, allowing for a wide range of speeds and precise control of operations. The operating weight is 5621.8 lbs, and it features a hitch system categorized as a Category II with a maximum lift capacity of 3307 lbs. This tractor's tire sizes are 8-16 for the front and 12.4-24 for the rear. Notable features include a 130 A alternator and a hydraulic system with a flow capacity of 18.1 gallons per minute. Specific details such as the type of chassis, steer system, and brake system are not provided without further data.
Show more...

Key Specifications

Category: Utility

Power Output: 95

Operating Weight: 5621.8

Fuel Type: diesel

Lift Capacity: 3307 lbs

Image Gallery

Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor Kubota M5N-091HDCC24 Tractor

Kubota M5N-091HDCC24 vs. Similar Tractors

Power Output
Above Average
Greater than 80% of similar tractors.
Hitch Capacity
Average
Greater than 60% of similar tractors.
Operating Weight
Average
Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V-3800-CR-TIER4
Cooling Type
water-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
Turbocharged
Cylinders
4
Displacement (ci)
-
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
95

Transmission

Type
-
Forward Gears
24
Reverse Gears
24
Total Gears
48

Dimensions

Length (in)
-
Width (in)
49.2
Height (in)
91.2
Operating Weight (lb)
5621.8

Power Take-Off (PTO)

PTO Type
Electro-hydraulic
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
16
Front Tire Width (in)
8
Rear Tire Diameter (in)
24
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Rigid lower link, easy adjust stabilizers
Hitch Category
II
Hitch Position
-
Hitch Capacity (lb)
3307 lbs
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
