Kubota M4062

Last Updated: June 2024

Overview

The Kubota M4062 is a utility tractor that comes equipped with a 4-wheel drive system and power steering, enhancing its maneuverability and versatility on various terrains. At its heart, the tractor has a reliable Kubota V3307 diesel engine with a displacement of 203.3 cubic inches, producing 66 horsepower at a rated RPM of 2400. The tractor's cooling mechanism is liquid-based, ensuring efficient thermal regulation during heavy operations. The M4062 offers an 18-speed transmission, providing a robust set of gear options for both forward and reverse movement, complemented by a wet disc clutch. With dimensions of 145.7 inches in length and a cab height of 101.6 inches, and varying weights between 5666 lbs (ROPS) and 6702 lbs (Cab), the M4062 series was manufactured from 2018 to 2020 and sits on a wheelbase of 84.1 inches, contributing to its stable and supportive structure. This model's tire configuration uses ag tires, with specifications for the standard tires presented as front: 320/85R20 and rear: 420/85R30. While the exact hitch type and hydraulic system remain unspecified, this utility tractor can be presumed to have the typical capabilities found in its class, including a Three-Point Hitch of a Category 3 standard, though the exact lift capacity is not mentioned.
Show more...

Key Specifications

Category: Utility

Power Output: 66

Drive Type: 4WD

Operating Weight: 6702

Fuel Type: Diesel

Kubota M4062 vs. Similar Tractors

Power Output
Average
Greater than 62% of similar tractors.
Operating Weight
Average
Greater than 51% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V3307
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
203.3
Bore (in)
3.7
Stroke (in)
4.7
Rated RPM
2400
Power Output (hp)
66

Transmission

Type
-
Forward Gears
18
Reverse Gears
18
Total Gears
-

Dimensions

Length (in)
145.7
Width (in)
-
Height (in)
101.6
Operating Weight (lb)
6702

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2020
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
