Kubota M10570

Last Updated: September 2024

Overview

The Kubota M10570 is a powerful utility tractor built for tough farm work. It has a strong 105 hp diesel engine with five cylinders, which is more powerful than most tractors in its class. The engine is liquid-cooled and made by Kubota themselves, known for reliable farm equipment.

This tractor is very versatile, with four-wheel drive and a 40-speed transmission (32 forward and 8 reverse gears). It's big and sturdy, weighing 8,179 pounds, which is above average for its type. The M10570 has large agricultural tires and a three-point hitch, making it great for pulling heavy farm tools. It's also quite tall at 104 inches, giving the driver a good view of the field. With its strong engine and durable build, this Kubota tractor is ready to handle a wide range of farm tasks with ease.
Show more...

Key Specifications

Category: Utility

Power Output: 105 hp (78.3 kW)

Drive Type: MFWD(4WD)

Operating Weight: 8179 lb (3710 kg)

Fuel Type: Diesel

Kubota M10570 vs. Similar Tractors

Power Output

The Power Output for the Kubota M10570 is Above Average. It is greater than 85% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Kubota M10570 is Above Average. It is greater than 78% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Kubota M10570 is Above Average. It is greater than 86% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Kubota M10570 is Average. It is greater than 51% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kubota
Model
F5400
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Cylinders
5
Displacement
330 ci (5.4 L)
Bore
4.29 in (109.0 mm)
Stroke
4.57 in (116.1 mm)
Rated RPM
2400
Power Output
105 hp (78.3 kW)

Transmission

Forward Gears
32
Reverse Gears
8
Total Gears
40

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
MFWD(4WD)
