Kubota M1-65

Last Updated: June 2024

Overview

The Kubota M1-65 is a utility tractor designed with versatility and robustness in mind. It features a 4-wheel drive chassis with a Multiple Gear Drive Forward and Reverse system, making it adept for various farming tasks. The tractor is powered by a 65 horsepower Kubota D3502 diesel engine, offering sufficient power and torque for a wide range of agricultural operations. With a wheelbase of 83.3 inches and a weight of 5688 lbs, it has a sturdy and stable presence. The tractor's clearance at the rear axle of 16.3 inches is suitable for numerous field applications. With the production spanning from 1988 to 1998, this model stood the test of time in terms of reliability and utility.

Key Specifications

Category: Utility

Power Output: 65

Transmission: Creeper

Drive Type: 4WD

Operating Weight: 5688

Fuel Type: Diesel

Image Gallery

Kubota M1-65 Tractor

Kubota M1-65 vs. Similar Tractors

Power Output

Average

Greater than 61% of similar tractors.

Operating Weight

Average

Greater than 46% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: D3502
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 3
Displacement (ci): 213.5
Bore (in): 4.29
Stroke (in): 4.92
Rated RPM: 2400
Power Output (hp): 65

Transmission

Type: Creeper
Forward Gears: 18
Reverse Gears: 18
Total Gears: -

Dimensions

Length (in): 144.5
Width (in): 69.3
Height (in): 99.2
Operating Weight (lb): 5688

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: -
Coolant Capacity (qts): -
Front Tire Diameter (in): 24
Front Tire Width (in): 8.3
Rear Tire Diameter (in): 36
Rear Tire Width (in): 12.4
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 1998
Hitch Type: JIS1
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: -
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
