Kubota LX3310

Last Updated: June 2024

Overview

The Kubota LX3310 is a compact utility tractor that pairs functionality with a user-friendly design, making it suitable for a variety of tasks. This model features a reliable 4-cylinder, liquid-cooled V1505 Kubota diesel engine with a displacement of 91.5 cubic inches and a power output of 30.8 horsepower at a rated RPM of 2500. The LX3310 offers a robust hydrostatic transmission system with infinite forward and reverse gears spread over three ranges, allowing for precise speed adjustments and smoother operation. The tractor's 4WD MFWD chassis ensures better traction and control, especially when working on uneven terrain or slippery conditions. Operators can choose between an open station with ROPS or a cab configuration, each differing slightly in dimensions and weight. With a 65.5-inch wheelbase and a ground clearance of 14.6 inches, the tractor is designed to navigate through various working environments with ease.
Show more...

Key Specifications

Category: Utility

Power Output: 30.8

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: ROPS: 2072, Cab: 2557

Fuel Type: Diesel

Kubota LX3310 vs. Similar Tractors

Power Output
Below Average
Greater than 26% of similar tractors.
Operating Weight
Below Average
Greater than 17% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V1505
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
91.5
Bore (in)
3.07
Stroke (in)
3.09
Rated RPM
2500
Power Output (hp)
30.8

Transmission

Type
Hydrostatic
Forward Gears
Infinite (3-range)
Reverse Gears
Infinite (3-range)
Total Gears
-

Dimensions

Length (in)
ROPS: 101.8, Cab: 103.9
Width (in)
53.7
Height (in)
ROPS: 88.4, Cab: 84.6
Operating Weight (lb)
ROPS: 2072, Cab: 2557

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
4.5
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard: Agricultural, Optional: Industrial
Manufacture - End Year
-
Hitch Type
Category 1
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS or Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
Open Center
