Kubota L5460HSTCC

Last Updated: September 2024

Overview

The Kubota L5460HSTCC is a versatile utility tractor designed for various farming tasks. It features a four-wheel drive system and hydrostatic power steering, making it easy to maneuver in tight spaces. The tractor is powered by a Kubota diesel engine with 54 hp, which provides average power for its class. The engine has 4 cylinders and uses natural aspiration with exhaust gas recirculation for cleaner emissions.

This tractor comes with a hydrostatic transmission that offers 6 forward and 6 reverse gears, giving operators good control over speed and direction. It has a three-point hitch at the rear, capable of lifting up to 2,976.3 lb, which is above average for its size. The L5460HSTCC also features an independent PTO with two speed options: 540 rpm and 2000 rpm. The tractor's compact size, measuring 126.4 inches long and 68.4 inches wide, makes it suitable for working in smaller fields or around buildings. With a fuel capacity of 13.5 gallons and wet disc brakes, this Kubota model offers good efficiency and reliable stopping power for everyday farm use.
Show more...

Key Specifications

Category: Utility

Power Output: 54 hp (40.3 kW)

Transmission: HST Plus (Hydrostatic Transmission Plus)

Drive Type: Four-wheel drive (4WD)

Operating Weight: 4376 lb (1985 kg)

Fuel Type: Diesel

Kubota L5460HSTCC vs. Similar Tractors

Power Output

The Power Output for the Kubota L5460HSTCC is Average. It is greater than 52% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Operating Weight

The Operating Weight for the Kubota L5460HSTCC is Average. It is greater than 46% of similar Utility tractors in our database.

Operating weight distribution of Utility tractors

(across 4.4K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Kubota L5460HSTCC is Average. It is greater than 41% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Kubota L5460HSTCC is Above Average. It is greater than 77% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kubota
Model
L5460HSTCC
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
E-TVCS, indirect injection
Fuel Type
Diesel
Induction Type
Natural with EGR (Exhaust Gas Recirculation)
Cylinders
4
Displacement
148 ci (2.4 L)
Bore
3.50 in (88.9 mm)
Stroke
4.10 in (104.1 mm)
Rated RPM
2600
Power Output
54 hp (40.3 kW)

Transmission

Type
HST Plus (Hydrostatic Transmission Plus)
Forward Gears
6
Reverse Gears
6

Drivetrain

Chassis
4WD
Drive Type
Four-wheel drive (4WD)
Steering Type
Hydrostatic power steering
Brake Type
Wet disc type
