Kubota L5460HSTCC

Last Updated: June 2024

Overview

The Kubota L5460HSTCC is a utility tractor imbued with a combination of strength and refined operational control. It is powered by a robust Kubota diesel engine offering net power of 54 hp and gross power of 56 hp, which runs at a rated speed of 2600 RPM. The tractor utilizes a hydrostatic transmission with an HST Plus technology, providing six forward and reverse gears. Equipped with hydrostatic power steering for smooth operation, it delivers efficient maneuvering with a turning radius of merely 9.2 ft. This model supports a Category 2 three-point hitch with a lift capacity of almost 3000 pounds and it incorporates both front and rear PTO options, which are independently operable at 540 RPM for the rear and 2000 RPM mid-PTO. The L5460HSTCC has a well-rounded spec sheet suitable for a wide array of tasks, setting high standards for utility tractor performance and versatility.
Show more...

Key Specifications

Category: Utility

Power Output: Gross: 56 | Net: 54

Transmission: HST Plus (Hydrostatic Transmission Plus)

Drive Type: Four-wheel drive (4WD)

Operating Weight: 4376.2

Fuel Type: Diesel

Image Gallery

Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor Kubota L5460HSTCC Tractor

Kubota L5460HSTCC vs. Similar Tractors

Power Output
Excellent
Greater than 98% of similar tractors.
Hitch Capacity
Average
Greater than 54% of similar tractors.
Operating Weight
Average
Greater than 40% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
L5460HSTCC
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
E-TVCS, indirect injection
Fuel Type
Diesel
Induction Type
Natural with EGR (Exhaust Gas Recirculation)
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.5
Stroke (in)
4.1
Rated RPM
2600
Power Output (hp)
Gross: 56 | Net: 54

Transmission

Type
HST Plus (Hydrostatic Transmission Plus)
Forward Gears
6
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
126.4
Width (in)
5.7 ft (68.4 inches)
Height (in)
7.8 ft (93.6 inches)
Operating Weight (lb)
4376.2

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4WD
Drive Type
Four-wheel drive (4WD)
Steering Type
Hydrostatic power steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 1 & 2
Hitch Category
Category 2
Hitch Position
Rear
Hitch Capacity (lb)
2976.3 lbs at 24 inches
Operator Station Type
-
Starter Type
-
Brake Type
Wet disc type
Hydraulic System Type
-
