Kubota L5040

Last Updated: June 2024

Overview

The Kubota L5040 is a compact utility tractor that was manufactured by Kubota between 2007 and 2013. This model comes with a 4x4 MFWD 4WD chassis and is equipped with hydrostatic power steering, making maneuvering and handling easier for the operator. It has a Glide Shift (GST) transmission, with 12 forward and 8 reverse gears, allowing for a variety of speed options for different tasks. The L5040 has a liquid-cooled, turbocharged diesel engine that generates 52 horsepower and operates at 2600 RPM. The tractor has an open center hydraulic system and multiple tire options, including agricultural, lawn/turf, and industrial configurations. A category 3 three-point hitch and a standard 12-volt electric starter system are also featured in this model. With dimensions of 126.4 inches in length, 67.3 inches in width, and a height of 98 inches (with ROPS), this tractor weights 3803 lbs and has a ground clearance of 15.7 inches, which together with its other specifications, makes it suitable for various tasks in different settings.
Show more...

Key Specifications

Category: Utility

Power Output: 52

Transmission: Glide Shift (GST)

Drive Type: 4WD

Operating Weight: 3803

Fuel Type: diesel

Kubota L5040 vs. Similar Tractors

Power Output
Average
Greater than 50% of similar tractors.
Operating Weight
Average
Greater than 34% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
-
Cooling Type
liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
diesel
Induction Type
turbocharged
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.4
Stroke (in)
4
Rated RPM
2600
Power Output (hp)
52

Transmission

Type
Glide Shift (GST)
Forward Gears
12
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
126.4
Width (in)
67.3
Height (in)
98 (ROPS)
Operating Weight (lb)
3803

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
hydrostatic power steering
Coolant Capacity (qts)
8.7
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
ag, lawn/turf, industrial
Manufacture - End Year
2013
Hitch Type
Rear Type: I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
12 volt
Brake Type
-
Hydraulic System Type
open center
