Kubota L5030

Last Updated: July 2024

Overview

The Kubota L5030 is a versatile compact utility tractor, part of Kubota's L30 series, manufactured between 2003 and 2007. It is powered by a reliable four-cylinder Kubota V2403 diesel engine with a displacement of 148.5 cubic inches, delivering a power output of 50 hp. Available with multiple transmission options including hydrostatic, Glide Shift (GST), and a fully synchronized system with creep, the L5030 offers a range of speeds suitable for varying tasks. The tractor features hydrostatic power steering, wet disc brakes, and a choice of operator stations between a two-post ROPS or an optionally enclosed Grand Cab. Supporting a three-point hitch system of category II/I with a lift capacity of 3,860 lbs, this tractor is equipped to handle a variety of implements. Additional details such as total hydraulic flow, PTO speeds, operating weights, and dimensions contribute to the model's adaptability for farm and utility work.

Key Specifications

Category: Utility

Power Output: 50

Transmission: Multiple options: Hydrostatic; Glide Shift (GST); Fully synchronized main and shuttle with creep

Drive Type: MFWD

Operating Weight: 3,800 (ROPS Operating); 4,090 (Cab Shipping)

Fuel Type: Diesel

Image Gallery

Kubota L5030 Tractor

Kubota L5030 vs. Similar Tractors

Power Output

Average

Greater than 49% of similar tractors.

Hitch Capacity

Poor

Greater than 10% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: V2403
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 4
Displacement (ci): 148.6
Bore (in): 3.425
Stroke (in): 4.031
Rated RPM: 2700
Power Output (hp): 50

Transmission

Type: Multiple options: Hydrostatic; Glide Shift (GST); Fully synchronized main and shuttle with creep
Forward Gears: -
Reverse Gears: -
Total Gears: Infinite forward and reverse (3-range); 12 forward and 8 reverse; 16 forward and 16 reverse (assuming different options)

Dimensions

Length (in): 127.8
Width (in): 57.9
Height (in): 89.6 (ROPS); 89.4 (Cab)
Operating Weight (lb): 3,800 (ROPS Operating); 4,090 (Cab Shipping)

Power Take-Off (PTO)

PTO Type: Independent
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 2,000 (Mid PTO)
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: MFWD
Steering Type: Hydrostatic power
Coolant Capacity (qts): 9.7
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2007
Hitch Type: Three-Point Hitch
Hitch Category: II/I
Hitch Position: Rear
Hitch Capacity (lb): 3,860
Operator Station Type: Two-post ROPS or Grand Cab (optional)
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: Open center

Test Results

Nebraska Tractor Test Laboratory - Test Date: November 14 to November 16, 2006

Maximum Power and Fuel Consumption

Maximum Power at Rated Engine Speed: 45.86 HP (34.20 kW) at 2700 rpm
Fuel Consumption at Maximum Power: 3.23 Gal/hr (12.22 l/h) with a fuel efficiency of 0.493 lb/hp.hr (0.300 kg/kW.h)
Fuel Consumption at Standard PTO Speed (540 rpm): 44.80 HP (33.41 kW) at 2550 rpm with 3.08 Gal/hr (11.68 l/h) and a fuel efficiency of 0.482 lb/hp.hr (0.293 kg/kW.h)

Drawbar Performance

Maximum Drawbar Power: Not specified in the provided data.
Fuel Consumption at Various Power Levels:
40.31 HP (30.06 kW) at 2804 rpm: 2.93 Gal/hr (11.08 l/h), 0.509 lb/hp.hr (0.309 kg/kW.h)
30.75 HP (22.93 kW) at 2841 rpm: 2.37 Gal/hr (8.97 l/h), 0.540 lb/hp.hr (0.328 kg/kW.h)
20.77 HP (15.49 kW) at 2867 rpm: 1.93 Gal/hr (7.30 l/h), 0.650 lb/hp.hr (0.395 kg/kW.h)

Torque and Engine Performance

Maximum Torque: 108 lb.-ft. (146 Nm) at 1701 rpm
Torque Rise: 20.8%

Hydraulic Performance

Maximum Force Exerted (Category I): 3137 lbs (14.0 kN)
Maximum Force Exerted (Category II): 2813 lbs (12.5 kN)
Pump Delivery Rate: 9.8 GPM (37.1 l/min) at minimum pressure and rated engine speed
Hydraulic Power: 12.5 HP (9.3 kW) at delivery pressure of 2200 psi (152 bar)

Sound Levels

Operator's Ear at No Load in 8th Gear: 87.3 dB(A)
Bystander: 80.2 dB(A)

Nebraska Tractor Test Lab.(2006).Nebraska OECD Tractor Test 1891 for Kubota L5030 Diesel. Lincoln, NE:Nebraska Tractor Test Laboratory. Retrieved from https://digitalcommons.unl.edu/tractormuseumlit/362
