Kubota L4760

Last Updated: June 2024

Overview

The Kubota L4760 is a versatile and powerful compact utility tractor designed for a variety of tasks. Manufactured by Kubota since 2013, it is part of the respected L60 series. It boasts a four-cylinder, liquid-cooled Kubota V2403-CR-E4 diesel engine with a displacement of 148.5 ci and a power output of 49 hp. The tractor features hydrostatic power steering and is equipped with either a hydrostatic transmission (HST Plus) with infinite three-range gears for both forward and reverse or a glide shift transmission (GST) with 12 forward and 8 reverse gears. The L4760 meets Tier IV emissions standards through exhaust gas recirculation (EGR). It can be configured with either an open operator station with ROPS or a more comfortable Grand Cab with air conditioning. With a strong three-point hitch capable of lifting 3,859 lbs and a choice of a 540 rpm PTO or an optional 2,000 rpm middle PTO, the Kubota L4760 facilitates a wide range of attachments and implements for various agricultural and maintenance activities.
Show more...

Key Specifications

Category: Utility

Power Output: 49 (gross)

Transmission: Hydrostatic (HST) / Glide Shift (GST)

Drive Type: 4WD

Operating Weight: 3847 to 4222

Fuel Type: Diesel

Kubota L4760 vs. Similar Tractors

Power Output
Average
Greater than 47% of similar tractors.
Hitch Capacity
Poor
Greater than 9% of similar tractors.
Operating Weight
Above Average
Greater than 86% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2403-CR-E4
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2700 (GST)
Power Output (hp)
49 (gross)

Transmission

Type
Hydrostatic (HST) / Glide Shift (GST)
Forward Gears
Infinite (3-range) / 12 (GST)
Reverse Gears
Infinite (3-range) / 8 (GST)
Total Gears
-

Dimensions

Length (in)
121.5
Width (in)
66.5
Height (in)
97.6 (ROPS) / 91.1 (cab)
Operating Weight (lb)
3847 to 4222

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000 (optional middle PTO)
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
8.66
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
3,859 lbs
Operator Station Type
Open operator station with two-post foldable ROPS / Cab (option)
Starter Type
Electric
Brake Type
Wet disc
Hydraulic System Type
Open center
