Kubota L4701

Last Updated: June 2024

Overview

The Kubota L4701 is a compact utility tractor that offers versatility and robustness, catering to a variety of tasks. Manufactured since 2014, it features a Kubota V2403 four-cylinder diesel engine with a 2.4 L (148.5 ci) displacement. Operators can choose from two transmission types - an 8-speed synchronized shuttle or an infinite hydrostatic transmission with three ranges. The tractor's hydrostatic power steering and mechanical wet disc brakes make operation smooth and controlled. With an open operator station with two-post ROPS, this model promises comfort and safety. The L4701's Three-Point Hitch, Category 1, ensures compatibility with a vast array of implements, bolstered by its independent rear PTO with a 540 rpm rating.

Key Specifications

Category: Utility

Power Output: 44.8

Transmission: Synchronized shuttle or Hydrostatic

Drive Type: 2WD or 4WD

Operating Weight: 3219 (2WD Gear), 3296 (4WD Gear), 3307 (4WD Hydro)

Fuel Type: Diesel

Image Gallery

Kubota L4701 Tractor

Kubota L4701 vs. Similar Tractors

Power Output

Average

Greater than 41% of similar tractors.

Hitch Capacity

Average

Greater than 52% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: V2403
Cooling Type: Liquid
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 4
Displacement (ci): 148.5
Bore (in): 3.43
Stroke (in): 4.03
Rated RPM: 2600
Power Output (hp): 44.8

Transmission

Type: Synchronized shuttle or Hydrostatic
Forward Gears: 8 synchronized shuttle / Infinite hydrostatic
Reverse Gears: 8 synchronized shuttle / Infinite hydrostatic
Total Gears: -

Dimensions

Length (in): 119.5 (4WD), 122.8 (2WD)
Width (in): 62.4
Height (in): 91.7
Operating Weight (lb): 3219 (2WD Gear), 3296 (4WD Gear), 3307 (4WD Hydro)

Power Take-Off (PTO)

PTO Type: Independent with hydraulic wet disc clutch
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: -
Drive Type: 2WD or 4WD
Steering Type: Hydrostatic power
Coolant Capacity (qts): 6.87
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag, Lawn/turf, Industrial
Manufacture - End Year: -
Hitch Type: Three-Point Hitch
Hitch Category: Category 1
Hitch Position: Rear
Hitch Capacity (lb): 2867
Operator Station Type: Open with two-post ROPS
Starter Type: Electric
Brake Type: Mechanical wet disc
Hydraulic System Type: Open Center
