Kubota L4400HST

Last Updated: June 2024

Overview

The Kubota L4400HST is a versatile tractor that balances power and ease of use for a variety of tasks. It offers a hydrostatic transmission likely with three ranges, providing adjustable speed for precision tasks or transportation. This is complemented by a robust engine from Kubota, the E-TVCS model, with a net power output of 43 hp and a displacement of 134.1 cubic inches. Although specifics like cooling type and induction type are not provided, such an engine typically features efficient combustion and steady power delivery, adequate for tough working conditions. Operating at a weight of 3307 pounds, it has a lift capacity of 2321.5 lbs at the rear hitch, hinting at good capacity for implements and attachments. Specifics of the chassis are not disclosed, but standard tire sizing figures and the inclusion of a hydrostatic transmission suggest it is likely designed for varied agricultural tasks with an emphasis on maneuverability and consistent performance.
Show more...

Key Specifications

Category: Utility

Power Output: 43

Transmission: Hydrostatic

Drive Type: HST (assumed from model name)

Operating Weight: 3307

Fuel Type: Diesel (inferred from engine model and commonality in tractors)

Kubota L4400HST vs. Similar Tractors

Power Output
Average
Greater than 40% of similar tractors.
Hitch Capacity
Average
Greater than 40% of similar tractors.
Operating Weight
Below Average
Greater than 28% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
E-TVCS
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel (inferred from engine model and commonality in tractors)
Induction Type
-
Cylinders
4
Displacement (ci)
134.1
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
43

Transmission

Type
Hydrostatic
Forward Gears
3 (assumed from "hydrostatic 3 range")
Reverse Gears
3 (assumed from "hydrostatic 3 range")
Total Gears
-

Dimensions

Length (in)
118.8 (inferred from 9.9 ft)
Width (in)
63.6 (inferred from 5.3 ft)
Height (in)
86.4 (inferred from 7.2 ft)
Operating Weight (lb)
3307

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
HST (assumed from model name)
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Three-Point Hitch
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
2321.5 lbs
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
