Kubota L4400 Gear

Last Updated: June 2024

Overview

The Kubota L4400 Gear tractor is a utility model designed with a robust engine, producing 45.3 horsepower at a rated RPM of 2600. This model features a sliding gear constant mesh transmission with 8 forward gears and 4 reverse gears, providing ample range for various tasks. It is equipped with a Category I three-point hitch at the rear, with a lift capacity of 2321.5 lbs, which is suitable for a variety of implements. The tractor's operating weight is listed at 3152.7 lbs. The engine has four cylinders and displaces 134.1 cubic inches, using an E-TVCS indirect injection system, indicative of a diesel fuel type. With an operating voltage of 12 V and a tire size specification of 7.5L-15 at the front and 14.9-24 at the rear, this tractor is built to handle a range of applications. The overall width of the tractor is 5.3 feet, and the height with cab or ROPS/FOPS is 7.2 feet. However, the actual length data seems to be incorrect as 9.9 inches is not feasible for the total length of a tractor, which would typically be measured in feet for a model of this type. Other detailed features such as the tire type, chassis and drive type, and detailed engine specifications like cooling type are not provided in the data and therefore are considered unknown.
Show more...

Key Specifications

Category: Utility

Power Output: 45.3

Transmission: Sliding gear constant mesh

Operating Weight: 3152.7

Fuel Type: Diesel

Lift Capacity: 2321.5

Kubota L4400 Gear vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Hitch Capacity
Average
Greater than 40% of similar tractors.
Operating Weight
Below Average
Greater than 26% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
L4400 Gear
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
E-TVCS indirect injection
Cylinders
4
Displacement (ci)
134.1
Bore (in)
-
Stroke (in)
-
Rated RPM
2600
Power Output (hp)
45.3

Transmission

Type
Sliding gear constant mesh
Forward Gears
8
Reverse Gears
4
Total Gears
-

Dimensions

Length (in)
Unknown (inaccurate data given as 9.9 in which is not possible)
Width (in)
63.6
Height (in)
86.4
Operating Weight (lb)
3152.7

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category I Three-Point Hitch
Hitch Category
Category I
Hitch Position
Rear
Hitch Capacity (lb)
2321.5
Operator Station Type
Unknown (data provided mentions both Cab and ROPS, impossible to determine which one applies without additional data)
Starter Type
-
Brake Type
-
Hydraulic System Type
-
