Kubota L4200

Last Updated: June 2024

Overview

The Kubota L4200 is a versatile and powerful compact utility tractor, suitable for a variety of agricultural tasks. Manufactured by Kubota between 1994 and 1999, the L4200 can be found with either 4x2 2WD or 4x4 MFWD 4WD, making it adaptable to different working conditions. It is powered by the reliable Kubota V2203-A engine, a 2.2-liter four-cylinder diesel engine providing 45.3 horsepower at 2600 RPM. This tractor also offers two transmission options to cater to the operator’s needs: a synchronized shuttle (FST) gearbox with 8 forward and reverse gears or a power shuttle (GST) gearbox with the same gear configuration. Equipped with an open operator station with two-post ROPS, hydrostatic power steering, and wet disc brakes, the L4200 is designed with functionality and operator comfort in mind. Its sturdy construction, including a lift capacity of 2,870 pounds at the hitch, further contributes to its reputation as a reliable workhorse in the field.
Show more...

Key Specifications

Category: Utility

Power Output: 45.3

Transmission: Synchronized shuttle or Power shuttle

Drive Type: 2WD or 4WD

Operating Weight: 2875 to 3500

Fuel Type: Diesel

Kubota L4200 vs. Similar Tractors

Power Output
Average
Greater than 43% of similar tractors.
Hitch Capacity
Average
Greater than 53% of similar tractors.
Operating Weight
Above Average
Greater than 84% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203-A
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.43
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
45.3

Transmission

Type
Synchronized shuttle or Power shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
118.9
Width (in)
62.4
Height (in)
84.4
Operating Weight (lb)
2875 to 3500

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
2WD or 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
7.9
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
1999
Hitch Type
Three-Point Hitch
Hitch Category
Category 1
Hitch Position
-
Hitch Capacity (lb)
2870 lbs
Operator Station Type
Open Station with ROPS
Starter Type
Electric
Brake Type
Wet disc
Hydraulic System Type
Open center
