Kubota L4060HSTCC

Last Updated: June 2024

Overview

The Kubota L4060HSTCC is a utility tractor largely defined by its versatility and power in a range of operational contexts. At the heart is a KUBOTA-manufactured, E-TVCS, 4-cycle diesel engine with a power output of 42 hp and a PTO power of 32.5 hp, paired with the highly efficient HST Plus transmission that offers 6 forward and reverse gears. Operating at a rated speed of 2600 rpm and featuring a liquid cooling system, this tractor's engine is both robust and reliable. Measuring 121.5 inches in length, 67.2 inches in width, and with a height of 91.2 inches to the top of the ROPS/FOPS, it has an operational weight of 4023.5 lbs. Equipped with wet disc brakes and a dry type single-stage clutch, it ensures smooth operation and control. The rear-positioned, Category 1 hitch is capable of lifting 2755.8 lbs, making it suitable for a variety of implements. The Kubota L4060HSTCC provides operators with modern conveniences such as hydrostatic power steering, a natural aspiration system with EGR for emission control, and a 60A alternator to power its electrical systems. The independent PTO with speeds of 540 and 2000 rpm additionally enhances its operational flexibility. It's designed to be user-friendly, with smooth maneuverability thanks to an 8.9 ft turning radius, a testament to its capability in both open fields and tighter spaces typical of smaller farms or orchard operations.
Show more...

Key Specifications

Category: Utility

Power Output: 42

Transmission: HST Plus

Drive Type: 4WD

Operating Weight: 4023.5

Fuel Type: Diesel

Kubota L4060HSTCC vs. Similar Tractors

Power Output
Average
Greater than 39% of similar tractors.
Hitch Capacity
Average
Greater than 51% of similar tractors.
Operating Weight
Average
Greater than 36% of similar tractors.

Technical Specifications

Engine

Manufacturer
KUBOTA
Model
L4060HSTCC
Cooling Type
Liquid-cooled
Cylinder Orientation
Vertical
Valve Configuration
Indirect injection
Fuel Type
Diesel
Induction Type
Natural with EGR
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.5
Stroke (in)
4.1
Rated RPM
2600
Power Output (hp)
42

Transmission

Type
HST Plus
Forward Gears
6
Reverse Gears
6
Total Gears
-

Dimensions

Length (in)
121.5
Width (in)
67.2
Height (in)
91.2
Operating Weight (lb)
4023.5

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4WD
Drive Type
4WD
Steering Type
Hydrostatic power steering
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Category 1
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
2755.8
Operator Station Type
-
Starter Type
-
Brake Type
Wet disc type
Hydraulic System Type
-
