Kubota L3940HST

Last Updated: June 2024

Overview

The Kubota L3940HST is a compact utility tractor, known for its versatility and efficiency. It is equipped with a Kubota E-TVCS engine which provides a gross power of 40.5 hp (30 kW) and a net power of 38.5 hp (28 kW). The engine runs at a rated speed of 2700 rpm, with a displacement of 122 cubic inches and has four cylinders. The tractor operates with a hybrid HST Plus transmission, offering 3 forward and 3 reverse gears. The operating weight of the L3940HST is 3626.7 lbs, making it a strong performer for a variety of tasks. It has a lift capacity of 2755.8 lbs at the three-point hitch, and its fuel capacity is 13.3 gallons to allow for extended work periods. The machine provides a comfortable turning radius of 8.9 feet, making it highly maneuverable in tight spaces. The maximum speed of 16.1 mph facilitates efficient movement between job sites. While exact tire sizes are noted, details such as bore and stroke, tire type, rim diameter, and the year of manufacture are not available, and the narrative does not speculate on these details.
Show more...

Key Specifications

Category: Utility

Power Output: 40.5

Transmission: HST Plus

Operating Weight: 3626.7

Lift Capacity: 2755.8

Kubota L3940HST vs. Similar Tractors

Power Output
Average
Greater than 38% of similar tractors.
Hitch Capacity
Average
Greater than 51% of similar tractors.
Operating Weight
Average
Greater than 32% of similar tractors.

Technical Specifications

Engine

Manufacturer
Unknown
Model
E-TVCS
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
natural
Cylinders
4
Displacement (ci)
122
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
40.5

Transmission

Type
HST Plus
Forward Gears
3
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
122.4 (assuming the overall length was intended to be 10.2 feet)
Width (in)
67.2 (assuming the width outside frame was intended to be 5.6 feet)
Height (in)
98.4 (assuming height was intended to be 8.2 feet)
Operating Weight (lb)
3626.7

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Cat. I
Hitch Category
Category 3 (assuming data error as the specification matches Category 1)
Hitch Position
-
Hitch Capacity (lb)
2755.8
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
