Kubota L3940GST

Last Updated: June 2024

Overview

The Kubota L3940GST is a mid-size utility tractor known for its versatility and power. Equipped with a four-wheel drive chassis and a Kubota E-TVCS engine, this tractor ensures reliable performance across a variety of farming and land maintenance tasks. The engine displaces 122 cubic inches and is naturally aspirated, coupled with a gross horsepower of 40.5 at 2700 RPM. It provides a substantial 33 horsepower to the PTO, vital for driving various tractor implements. This model features 12 forward gears and 8 reverse gears with a GST (Glide Shift Transmission), offering a wide range of speeds and smooth gear shifting, adapting to different work requirements. Its design comes practical with a lift capacity of 2755.8 lbs at the three-point hitch and a decently compact size, with an operating weight of 3527.4 lbs, aiding in maneuverability without sacrificing stability. The presence of 40 A alternator supplied amperage and a 13.3-gallon fuel capacity contributes to the tractor's operational longevity and efficiency. This summary provides owners a comprehensive understanding of the Kubota L3940GST's specifications and operational highlights, preparing them to fully exploit its features in their agricultural or utility work.
Show more...

Key Specifications

Category: Utility

Power Output: 40.5

Transmission: GST

Drive Type: 4WD

Operating Weight: 3527.4

Lift Capacity: 2755.8

Kubota L3940GST vs. Similar Tractors

Power Output
Average
Greater than 38% of similar tractors.
Hitch Capacity
Average
Greater than 51% of similar tractors.
Operating Weight
Average
Greater than 31% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
E-TVCS
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
natural
Cylinders
4
Displacement (ci)
122
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
40.5

Transmission

Type
GST
Forward Gears
12
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
10.2 (This value seems incorrect, should be reconsidered)
Width (in)
5.6 ft (67.2)
Height (in)
8.2 ft (98.4)
Operating Weight (lb)
3527.4

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 (4 wheels, all of which are powered)
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Cat. I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
2755.8
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
