Kubota L3901

Last Updated: June 2024

Overview

The Kubota L3901 is a 2WD or 4WD compact utility tractor from the Standard L series, produced by Kubota since 2014. It comes equipped with a Kubota D1803 three-cylinder diesel engine with two transmission options, gear shift with dual stage clutch or hydrostatic transmission. It features an open operator station with ROPS, wet disc brakes, integral power steering, and a fuel capacity of 11.1 US gallons. The tractor has options for agricultural, turf, or industrial tires and supports a rear three-point hitch in Category I with a rear PTO speed of 540 rpm. The L3901 offers a balance of power and performance with a gross horsepower of 37.5 HP and a rated RPM of 2700.

Key Specifications

Category: Utility

Power Output: 37.5

Transmission: Gear shift or Hydrostatic

Drive Type: 2WD or 4WD

Operating Weight: 2590 (2WD) or 2778 (4WD Hydro)

Fuel Type: Diesel

Image Gallery

Kubota L3901 Tractor

Kubota L3901 vs. Similar Tractors

Power Output

Average

Greater than 34% of similar tractors.

Hitch Capacity

Average

Greater than 34% of similar tractors.

Operating Weight

Excellent

Greater than 95% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: D1803
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 3
Displacement (ci): 111.4
Bore (in): 3.43
Stroke (in): 4.03
Rated RPM: 2700
Power Output (hp): 37.5

Transmission

Type: Gear shift or Hydrostatic
Forward Gears: 8 forward (Gear shift) or Infinite (Hydrostatic)
Reverse Gears: 8 reverse (Gear shift) or Infinite (Hydrostatic)
Total Gears: -

Dimensions

Length (in): 110.6 (2WD) or 107.9 (4WD)
Width (in): 55.1
Height (in): 91.7
Operating Weight (lb): 2590 (2WD) or 2778 (4WD Hydro)

Power Take-Off (PTO)

PTO Type: Live
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x2 2WD or 4x4 MFWD 4WD
Drive Type: 2WD or 4WD
Steering Type: Power
Coolant Capacity (qts): 6.34
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag, Lawn/turf, Industrial
Manufacture - End Year: -
Hitch Type: -
Hitch Category: I
Hitch Position: Rear
Hitch Capacity (lb): 1985
Operator Station Type: Open with two-post ROPS
Starter Type: Electric
Brake Type: Wet disk
Hydraulic System Type: Open center
