Kubota L3830HST

Last Updated: June 2024

Overview

The Kubota L3830HST is a tractor that seems to be designed for a range of utility jobs, significantly benefited by its hydrostatic transmission with 3 ranges which provides greater ease of use and efficiency in speed control. The tractor operates with a three-cylinder Kubota engine model L3830 HST, which provides a gross power output of 39 hp and is rated at 2700 RPM. It has a displacement of 111.5 cubic inches and a unique E-TVCS (Emissions - Three Vortex Combustion System) for its induction type, which pertains to the method of injecting fuel into the combustion chamber. The overall operating weight is just over 3340 lbs, which combined with its power makes it suitable for a variety of tasks while maintaining a balance between size and performance. Data such as the detailed dimensions of the tires, the cooling type of the engine, the orientation of the cylinders, and many other detailed specifications are not provided, which would be beneficial to have a fuller picture of the tractor's capabilities.
Show more...

Key Specifications

Category: Utility

Power Output: 39

Transmission: HST (Hydrostatic Transmission) with 3 ranges

Operating Weight: 3340.1

Lift Capacity: 2755.8

Kubota L3830HST vs. Similar Tractors

Power Output
Average
Greater than 35% of similar tractors.
Hitch Capacity
Average
Greater than 51% of similar tractors.
Operating Weight
Below Average
Greater than 28% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
L3830 HST
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
-
Induction Type
E-TVCS indirect injection
Cylinders
3
Displacement (ci)
111.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
39

Transmission

Type
HST (Hydrostatic Transmission) with 3 ranges
Forward Gears
3
Reverse Gears
3
Total Gears
-

Dimensions

Length (in)
117.6
Width (in)
67.2
Height (in)
91.2
Operating Weight (lb)
3340.1

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Cat. I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
2755.8
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
