Kubota L3430DT

Last Updated: June 2024

Overview

The Kubota L3430DT is a utility tractor designed for a variety of tasks that require a versatile and robust machine. With its 4-wheel drive chassis and an FST transmission offering eight forward and eight reverse gears, this tractor is engineered to provide reliable performance and maneuverability. The E-TVCS indirect injection system, combined with a displacement of 100.5 cubic inches and a 3-cylinder diesel engine rated at 33.6 horsepower, deliver dependable power for various operations. The machine operates on a 12V system with a 40A alternator and delivers a maximum speed of 16.6 mph, complemented by a tight turning radius of 8.9 feet for agile operations in diverse environments. The Cat 3 three-point hitch with a lift capacity of 2645.6 lbs enables the L3430DT to handle substantial implements with ease. A notable feature is the generous pump flow capacity of 13.3 gallons per minute, indicating a capable hydraulic system conducive for a range of attachments. Measuring 115.2 inches in length and standing 85.2 inches tall, the tractor maintains a moderate footprint and is suited for tasks in confined spaces as well as open fields.
Show more...

Key Specifications

Category: Utility

Power Output: 33.6

Transmission: FST

Drive Type: 4WD

Operating Weight: 3218.8

Fuel Type: Diesel

Kubota L3430DT vs. Similar Tractors

Power Output
Below Average
Greater than 29% of similar tractors.
Hitch Capacity
Average
Greater than 46% of similar tractors.
Operating Weight
Below Average
Greater than 27% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
L3430 DT
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
E-TVCS indirect injection
Cylinders
3
Displacement (ci)
100.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
33.6

Transmission

Type
FST
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
115.2
Width (in)
60
Height (in)
85.2
Operating Weight (lb)
3218.8

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4WD
Drive Type
4WD
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
-
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
2645.6
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
