Kubota L3400HST

Last Updated: June 2024

Overview

The Kubota L3400HST is a compact utility tractor that offers a blend of power, versatility, and ergonomic features. Equipped with a Kubota-engineered L3400HST engine, this model boasts 34.7 horsepower and is capable of running at up to 2700 RPM, with a PTO power of 27.5 horsepower. At the heart of its performance is a 100.5 cubic inch displacement and 3-cylinder configuration, enhanced by E-TVCS (Emissions-Three Vortex Combustion System) valve configuration for better fuel combustion. This tractor's operation is supported by a hydrostatic transmission, allowing for smooth and variable control of speed and power. The Kubota L3400HST provides a reliable option for those who require a compact tractor for a variety of tasks, from fieldwork to lawn care. Its operational weight of 2601.5 lbs and lift capacity of 1435.3 lbs through the Cat. I three-point hitch makes it well-suited for a range of attachments and implements.
Show more...

Key Specifications

Category: Utility

Power Output: 34.7

Transmission: Hydrostatic

Operating Weight: 2601.5

Lift Capacity: 1435.3

Kubota L3400HST vs. Similar Tractors

Power Output
Average
Greater than 30% of similar tractors.
Hitch Capacity
Below Average
Greater than 28% of similar tractors.
Operating Weight
Below Average
Greater than 21% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
L3400HST
Cooling Type
-
Cylinder Orientation
-
Valve Configuration
E-TVCS
Fuel Type
-
Induction Type
Indirect Injection
Cylinders
3
Displacement (ci)
100.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2700
Power Output (hp)
34.7

Transmission

Type
Hydrostatic
Forward Gears
-
Reverse Gears
-
Total Gears
-

Dimensions

Length (in)
106.8
Width (in)
51.6
Height (in)
85.2
Operating Weight (lb)
2601.5

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
-
Front Tire Diameter (in)
16
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Cat. I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
1435.3
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
