Kubota L2900

Last Updated: June 2024

Overview

The Kubota L2900 is a versatile compact utility tractor designed for a variety of tasks. Produced by Kubota during the years 1994 to 1999 as part of the Grand L series, it is available in both 2WD and 4WD configurations, ensuring adaptability to multiple terrains and operations. This model is propelled by a reliable Kubota D1503 three-cylinder diesel engine, which provides a respectable 32 horsepower. The L2900 comes with hydrostatic power steering to facilitate maneuverability and wet disc brakes for reliable stopping power. Available with either a synchronized shuttle or a power shuttle transmission, each offering 8 forward and 8 reverse speeds, it provides a tailored operational experience for the driver. The tractor's three-point hitch system demonstrates compatibility with various agricultural attachments, supporting a hitch lift capacity of 2,867 pounds. The L2900 is further equipped with an open operator station with two-post ROPS for operator safety, and a fuel tank capacity of 35.0 liters, letting it work for extended periods without frequent refueling. Its substantial operating weight ranging between 2,560 to 2,710 pounds coupled with its diesel engine enables the tractor to take on strenuous tasks with relative ease.
Show more...

Key Specifications

Category: Utility

Power Output: 32

Transmission: Synchronized shuttle or power shuttle

Drive Type: 2WD or 4WD

Operating Weight: 2560 to 2710

Fuel Type: Diesel

Kubota L2900 vs. Similar Tractors

Power Output
Below Average
Greater than 27% of similar tractors.
Hitch Capacity
Average
Greater than 52% of similar tractors.
Operating Weight
Above Average
Greater than 83% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1503
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural aspiration
Cylinders
3
Displacement (ci)
91.4
Bore (in)
3.27
Stroke (in)
3.64
Rated RPM
2700
Power Output (hp)
32

Transmission

Type
Synchronized shuttle or power shuttle
Forward Gears
8
Reverse Gears
8
Total Gears
-

Dimensions

Length (in)
110.6
Width (in)
52
Height (in)
82.3
Operating Weight (lb)
2560 to 2710

Power Take-Off (PTO)

PTO Type
Independent
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
2000
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x2 2WD or 4x4 MFWD 4WD
Drive Type
2WD or 4WD
Steering Type
Hydrostatic power
Coolant Capacity (qts)
7.4
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
1999
Hitch Type
Three-Point Hitch
Hitch Category
I
Hitch Position
Rear
Hitch Capacity (lb)
2867
Operator Station Type
Open operator station with two-post ROPS
Starter Type
Electric
Brake Type
Wet disc
Hydraulic System Type
Open center
