Kubota KT300

Last Updated: June 2024

Overview

The Kubota KT300 is a versatile compact utility tractor produced by Kubota between 2005 and 2008. It features a robust Kubota D1503 three-cylinder diesel engine with a displacement of 91.5 cubic inches, which delivers 29.6 horsepower at an operating RPM of 2700. The tractor's 4WD chassis and power steering ensure smooth maneuverability in a variety of conditions, making it suitable for a range of tasks on the farm or acreage. It comes equipped with a power shift transmission with 12 forward and reverse gears, facilitating efficient operations and ease of use. The KT300 offers various operator station types with ROPS and cab options, based on user preference and safety requirements. The front and rear tire specifications indicate a standard agricultural configuration, enhancing traction on challenging terrains.

Key Specifications

Category: Utility

Power Output: 29.6

Transmission: Power shift

Drive Type: 4WD

Operating Weight: ROPS gear: 2216 | ROPS Glideshift: 2260 | Cab gear: 2491 | Cab Glideshift: 2535

Fuel Type: Diesel

Image Gallery

Kubota KT300 Tractor

Kubota KT300 vs. Similar Tractors

Power Output

Below Average

Greater than 24% of similar tractors.

Operating Weight

Excellent

Greater than 99% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: D1503
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 3
Displacement (ci): 91.5
Bore (in): 3.27
Stroke (in): 3.64
Rated RPM: 2700
Power Output (hp): 29.6

Transmission

Type: Power shift
Forward Gears: 12
Reverse Gears: 12
Total Gears: -

Dimensions

Length (in): ROPS: 113.8 | Cab: 112.6
Width (in): 52.2
Height (in): ROPS: 77.2 | Cab: 79.3
Operating Weight (lb): ROPS gear: 2216 | ROPS Glideshift: 2260 | Cab gear: 2491 | Cab Glideshift: 2535

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): 26
Rear Tire Width (in): 11.2
Front/Rear Rim Diameter (in): -
Tire Type: Standard (ag)
Manufacture - End Year: 2008
Hitch Type: Category I
Hitch Category: Category 3 (assumed based on the company's typical configurations and the size of the tractor)
Hitch Position: Rear
Hitch Capacity (lb): -
Operator Station Type: ROPS/Cab
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
