Kubota KT235

Last Updated: June 2024

Overview

The Kubota KT235 is a compact utility tractor designed for a variety of tasks on a farm, garden, or homestead. Equipped with a 22.7 horsepower Kubota D1503 engine, it offers a dependable liquid-cooled diesel power source with a displacement of 91.5 cubic inches. The three-cylinder engine operates at a maximum rated RPM of 2500. This model has a 4-wheel drive chassis with a mechanical front-wheel drive (MFWD) and power steering for ease of maneuverability. It features a versatile power shift transmission with an impressive 48 forward and 30 reverse gears, providing a wide range of speed options for different tasks. The tractor's dimensions and weight vary depending on whether it is equipped with a ROPS or cab configuration. Production of the KT235 ran from 2009 to 2011, and this model includes the Glideshift feature, enhancing the functionality of the transmission for smoother operation. The tractor supports a rear Category I hitch, but lift capacity details are not provided, and the type of PTO and brake system are unspecified as well.
Show more...

Key Specifications

Category: Utility

Power Output: 22.7

Transmission: Power shift

Drive Type: 4WD

Operating Weight: ROPS Gear: 2050 | ROPS Glideshift: 2094 | Cab Gear: 2293 | Cab Glideshift: 2337

Fuel Type: Diesel

Kubota KT235 vs. Similar Tractors

Power Output
Below Average
Greater than 13% of similar tractors.
Operating Weight
Excellent
Greater than 99% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1503
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
91.5
Bore (in)
3.27
Stroke (in)
3.64
Rated RPM
2500
Power Output (hp)
22.7

Transmission

Type
Power shift
Forward Gears
48
Reverse Gears
30
Total Gears
-

Dimensions

Length (in)
ROPS Length: 112.4 | Cab Length: 111.8
Width (in)
ROPS Width: 46.5 | Cab Width: 51.6
Height (in)
ROPS: 75 | Cab: 76
Operating Weight (lb)
ROPS Gear: 2050 | ROPS Glideshift: 2094 | Cab Gear: 2293 | Cab Glideshift: 2337

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard: Agricultural
Manufacture - End Year
2011
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS / Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
