Kubota KL5550

Last Updated: June 2024

Overview

The Kubota KL5550 is a Compact Utility tractor that was manufactured between 2010 and 2011. It features a four-wheel drive chassis with a 4x4 MFWD 4WD configuration and power steering for easy maneuverability. The tractor is powered by a 54.3 horsepower Kubota V2403 diesel engine. With a liquid-cooling system, the engine displaces 148.5 cubic inches with a bore and stroke of 3.43 inches by 4.03 inches, and operates at a rated RPM of 2700. The transmission is a 30-speed with 30 forward and 20 reverse gears, complemented by a dry disc clutch. The Kubota KL5550 provides a wheelbase of 76.4 inches, has a ground clearance of 17.3 inches, and weighs approximately 4012 pounds. It offers different height options with ROPS and cab configurations measuring at 93.3 inches and 89 inches, respectively. Standard tire fitments for this model are 8.3-20 at the front and 13.6-28 at the rear. This tractor would be well-suited to a variety of tasks on a small to medium-sized farm, providing ample power and versatility.
Show more...

Key Specifications

Category: Utility

Power Output: 54.3

Drive Type: MFWD (Mechanical Front Wheel Drive)

Operating Weight: 4012

Fuel Type: Diesel

Kubota KL5550 vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Average
Greater than 36% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2403
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2700
Power Output (hp)
54.3

Transmission

Type
-
Forward Gears
30
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
139.2
Width (in)
60.4
Height (in)
93.3 (ROPS), 89 (Cab)
Operating Weight (lb)
4012

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
MFWD (Mechanical Front Wheel Drive)
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2011
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
