Kubota KL550 Hi-Speed

Last Updated: June 2024

Overview

The Kubota KL550 Hi-Speed is a compact utility tractor, engineered to deliver a balance of size, power, and maneuverability. It features a 4x4 MFWD 4WD chassis that enhances traction and performance in various conditions. The tractor is powered by a reliable Kubota V2403 diesel engine with a displacement of 148.5 cubic inches that produces 54.3 horsepower at 2700 RPM, suitable for a range of agricultural tasks. This model offers a 30 forward and 20 reverse transmission, though the type of transmission is not specified. The steering is power-assisted, simplifying operator control during extended usage. Measuring 139.8 inches in length, 60.4 inches in width, and 87.4 inches in height, the KL550 Hi-Speed presents a compact but durable profile, with an operational weight of 4079 pounds. The tractor rides on standard agricultural tires, with sizes 8.3-20 for the front and 12.4-32 for the rear, a setup that contributes to appropriate clearance and stability. The known wheelbase of 76.4 inches aids in maintaining stability across a variety of terrain. The exact hitch type and hydraulic system info are not provided, and those interested should refer to the manufacturer or dealer details for specifics on these features and any additional implements for customization.
Show more...

Key Specifications

Category: Utility

Power Output: 54.3

Drive Type: 4WD

Operating Weight: 4079

Fuel Type: Diesel

Kubota KL550 Hi-Speed vs. Similar Tractors

Power Output
Average
Greater than 52% of similar tractors.
Operating Weight
Average
Greater than 37% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2403
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2700
Power Output (hp)
54.3

Transmission

Type
-
Forward Gears
30
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
139.8
Width (in)
60.4
Height (in)
87.4
Operating Weight (lb)
4079

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
