Kubota KL4750

Last Updated: June 2024

Overview

The Kubota KL4750 is a compact utility tractor, suitable for various agricultural tasks. It is equipped with a 46.3 horsepower Kubota V2403 diesel engine, known for its durability and efficient power delivery. With a large displacement of 148.5 cubic inches and liquid-cooling system, it is capable of sustained heavy-duty work. This model has a four-wheel drive (4WD) chassis with a 4x4 MFWD configuration, providing stability and traction across different terrains. The tractor features a 30-speed transmission with a dry disc clutch, 30 forward and 20 reverse gears, which allows for a versatile range of speed management for different tasks. With power steering and an electric starter, it offers convenience and ease of operation. The dimensions provide substantial ground clearance and a stable wheelbase, and the tractor can operate with either ROPS (Rollover Protection Structure) or a cab option, giving the operator flexibility in working conditions. The tractor was manufactured between the years 2010 to 2011.
Show more...

Key Specifications

Category: Utility

Power Output: 46.3

Drive Type: 4WD

Operating Weight: 3616 (ROPS), 4012 (cab)

Fuel Type: Diesel

Kubota KL4750 vs. Similar Tractors

Power Output
Average
Greater than 44% of similar tractors.
Operating Weight
Average
Greater than 31% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2403
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
4
Displacement (ci)
148.5
Bore (in)
3.43
Stroke (in)
4.03
Rated RPM
2700
Power Output (hp)
46.3

Transmission

Type
-
Forward Gears
30
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
139.2
Width (in)
60.4
Height (in)
93.3 (ROPS), 89 (cab)
Operating Weight (lb)
3616 (ROPS), 4012 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
20
Front Tire Width (in)
8.3
Rear Tire Diameter (in)
28
Rear Tire Width (in)
13.6
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2011
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
