Kubota KL4350

Last Updated: June 2024

Overview

The Kubota KL4350 is a compact utility tractor that was manufactured by Kubota between 2010 and 2011. It features a four-wheel drive chassis (4x4 MFWD 4WD), powered by a liquid-cooled, 134.1 cubic-inch, four-cylinder Kubota V2203 diesel engine with a power output of 42.4 horsepower and an operating RPM of 2700. Steering is power-assisted, enhancing maneuverability. The Kubota KL4350 employs a power shift transmission with 30 forward and 20 reverse gears, suitable for a wide range of tasks. This tractor has a wheelbase of 74.4 inches, a dry disc clutch, and standard agricultural tires with 8-18 on the front and 13.6-26 on the rear. Options for operator station include ROPS or an enclosed cab, with the weights being 3406 lbs and 3825 lbs, respectively. It remains a practical choice for a variety of agricultural and utility tasks.

Key Specifications

Category: Utility

Power Output: 42.4

Transmission: Power shift

Drive Type: 4WD

Operating Weight: ROPS Weight: 3406 | Cab Weight: 3825

Fuel Type: Diesel

Image Gallery

Kubota KL4350 Tractor

Kubota KL4350 vs. Similar Tractors

Power Output

Average

Greater than 39% of similar tractors.

Operating Weight

Above Average

Greater than 85% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: V2203
Cooling Type: Liquid-cooled
Cylinder Orientation: -
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Naturally aspirated
Cylinders: 4
Displacement (ci): 134.1
Bore (in): 3.43
Stroke (in): 3.64
Rated RPM: 2700
Power Output (hp): 42.4

Transmission

Type: Power shift
Forward Gears: 30
Reverse Gears: 20
Total Gears: -

Dimensions

Length (in): 135.6
Width (in): 58.9
Height (in): Height (ROPS): 91.3 | Height (cab): 86.6
Operating Weight (lb): ROPS Weight: 3406 | Cab Weight: 3825

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): -
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Standard ag
Manufacture - End Year: 2011
Hitch Type: Category I
Hitch Category: -
Hitch Position: -
Hitch Capacity (lb): -
Operator Station Type: ROPS available; Cab available
Starter Type: Electric
Brake Type: -
Hydraulic System Type: -
