Kubota KL410 Hi-Speed

Last Updated: June 2024

Overview

The Kubota KL410 Hi-Speed is a compact utility tractor designed for versatility and high performance in various tasks. It features a robust 4-wheel drive system (4x4 MFWD 4WD) complemented by power steering for enhanced maneuverability. The tractor is powered by a dependable Kubota V2203 diesel engine with a displacement of 134.1 ci, capable of delivering a power output of 41.4 horsepower. Equipped with a large capacity cooling system, it is built to sustain prolonged working hours without overheating. This model has a transmission offering 20 forward and reverse gears, ensuring operational efficiency and a wide range of speed options for different tasks. The machine presents various dimensions with a wheelbase of 74.4 inches, promoting stability across its applications. While the tractor's exact hitch specifications and hydraulic system details are unknown, it does feature a Category I rear hitch, empowering it to work with a wide array of implements. Height varies between 91.3 inches with ROPS and 84.7 inches with the cab, further indicating this model's emphasis on safety and operator comfort. The operating weight ranges from 3395 pounds with ROPS to 3792 pounds with the cab, illustrating the tractor's solid build and capability to handle significant loads.
Show more...

Key Specifications

Category: Utility

Power Output: 41.4

Drive Type: 4WD

Operating Weight: 3395 (ROPS), 3792 (cab)

Fuel Type: Diesel

Kubota KL410 Hi-Speed vs. Similar Tractors

Power Output
Average
Greater than 39% of similar tractors.
Operating Weight
Below Average
Greater than 29% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Natural
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.43
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
41.4

Transmission

Type
-
Forward Gears
20
Reverse Gears
20
Total Gears
40

Dimensions

Length (in)
135.6
Width (in)
58.9
Height (in)
91.3 (ROPS), 84.7 (cab)
Operating Weight (lb)
3395 (ROPS), 3792 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
26
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard Ag
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
-
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS (Roll-Over Protection Structure), Cab (Unknown if Optional or Standard)
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
