Kubota KL385

Last Updated: June 2024

Overview

The Kubota KL385 is a compact utility tractor designed for a variety of tasks on a small farm or acreage. Equipped with a 37.4 horsepower Kubota V2203 diesel engine, this tractor offers a reliable power source coupled with a liquid-cooling system to maintain optimal operating temperatures. The KL385 comes with a 4x4 MFWD 4WD chassis ensuring better traction on challenging terrains. The power steering feature provides ease of maneuverability, making it suitable for both novice and experienced operators. This model uses a manual transmission with an impressive 24 forward and 16 reverse gears, giving the operator a range of speed options for different tasks. Various practical aspects of this tractor, such as its wheelbase of 74.4 inches and a weight ranging from 3351 to 3781 pounds, underline its stable and robust build suitable for various agricultural tasks. Tire specifications were not provided, but it typically comes with standard agricultural (ag) tires. The tractor has a good ground clearance of 15.8 inches, necessary for operation in uneven fields. Furthermore, the Kubota KL385 was manufactured between 2008 and 2009.
Show more...

Key Specifications

Category: Utility

Power Output: 37.4

Transmission: Manual

Drive Type: 4WD

Operating Weight: 3351 (ROPS), 3781 (cab)

Fuel Type: Diesel

Kubota KL385 vs. Similar Tractors

Power Output
Average
Greater than 34% of similar tractors.
Operating Weight
Below Average
Greater than 29% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V2203
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
134.1
Bore (in)
3.43
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
37.4

Transmission

Type
Manual
Forward Gears
24
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
125.2
Width (in)
58.9
Height (in)
91.3 (ROPS), 86.6 (cab)
Operating Weight (lb)
3351 (ROPS), 3781 (cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2009
Hitch Type
Category I
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
-
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
