Kubota KL28 Hi-Speed

Last Updated: June 2024

Overview

The Kubota KL28 Hi-Speed is a compact utility tractor known for its 4WD system and robust power despite its compact frame. It comes equipped with a Kubota D1703 three-cylinder, diesel, liquid-cooled engine, delivering a power output of 27.6 hp and operating at a rated speed of 2600 RPM. It has an electric starter with a 12-volt starter voltage. The tractor offers substantial maneuverability and control with power steering and a 20-speed or possibly even a 30 forward and 20 reverse gear transmission system. Featuring different configurations, the tractor weight varies with the ROPS (Roll-Over Protection Structure) and cab versions, with the latter weighing 3219 pounds. This tractor is equipped with agricultural tires and can come with various tread and wheelbase configurations to suit different farming needs. The spacious cab design provides increased comfort, and at 81.7 inches in height, it offers good visibility for a variety of farm tasks. The KL28 Hi-Speed is designed to deliver reliable performance and versatility in a range of agricultural applications. It is a formidable player in the compact utility tractor market segment.
Show more...

Key Specifications

Category: Utility

Power Output: 27.6

Drive Type: 4WD

Operating Weight: 3219 (for cab configuration)

Fuel Type: Diesel

Kubota KL28 Hi-Speed vs. Similar Tractors

Power Output
Below Average
Greater than 22% of similar tractors.
Operating Weight
Below Average
Greater than 27% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1703
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
100.5
Bore (in)
3.43
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
27.6

Transmission

Type
-
Forward Gears
30
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
124 (for cab configuration)
Width (in)
54 (for cab configuration)
Height (in)
81.7 (for cab configuration)
Operating Weight (lb)
3219 (for cab configuration)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
Unknown - Data provided does not clearly indicate diameter, presenting inconsistent tire specifications.
Front Tire Width (in)
Unknown - Data provided does not clearly indicate width, presenting inconsistent tire specifications.
Rear Tire Diameter (in)
Unknown - Data provided does not clearly indicate diameter, rear tire size provided without diameter information.
Rear Tire Width (in)
Unknown - Data provided does not clearly indicate width, rear tire size provided without width information.
Front/Rear Rim Diameter (in)
-
Tire Type
Ag (Agricultural)
Manufacture - End Year
-
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Both ROPS and Cab available
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
