Kubota KL2750

Last Updated: June 2024

Overview

The Kubota KL2750 is a compact utility tractor, part of Kubota's KL Kingwel 50 Series, manufactured between 2010 and 2011. It is equipped with a Kubota D1703 3-cylinder diesel engine that provides 26.6 horsepower and a displacement of 100.5 cubic inches. The tractor boasts a 4x4 MFWD 4WD chassis, powered by a power shift Glideshift transmission with 30 forward and 20 reverse gears, offering versatility and ease of operation. The tractor's power steering and liquid cooling system contribute to its reliability and comfort of use. With a wheelbase of 65.8 inches and an operating weight ranging from 2778 pounds with ROPS to 3219 pounds with a cab, the KL2750 was designed to be a robust and capable machine for a variety of tasks. It has a hitch Category 3, but details of the hitch type and hitch lift capacity are unspecified. The tractor's dimensions provide good clearance and stability with a ground clearance of 13.6 inches. The standard setup of the tractor includes agricultural tires with front 6-14 and rear 9.5-24 sizes, ensuring adequate traction and performance in a range of farm operations.
Show more...

Key Specifications

Category: Utility

Power Output: 26.6

Transmission: Power shift

Drive Type: 4WD

Operating Weight: 2778 (ROPS), 3219 (Cab)

Fuel Type: Diesel

Kubota KL2750 vs. Similar Tractors

Power Output
Below Average
Greater than 20% of similar tractors.
Operating Weight
Below Average
Greater than 23% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1703
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
3
Displacement (ci)
100.5
Bore (in)
3.4
Stroke (in)
3.6
Rated RPM
2700
Power Output (hp)
26.6

Transmission

Type
Power shift
Forward Gears
30
Reverse Gears
20
Total Gears
-

Dimensions

Length (in)
121.7
Width (in)
53.2 (ROPS), 54.1 (Cab)
Height (in)
78 (ROPS), 84.8 (Cab)
Operating Weight (lb)
2778 (ROPS), 3219 (Cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
24
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
2011
Hitch Type
-
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
