Kubota KL24R

Last Updated: September 2024

Overview

The Kubota KL24R is a compact utility tractor built from 2012 to 2015. It's a 4-wheel drive machine with power steering, making it easy to handle in tight spaces. The tractor has a 16-speed power shift transmission, giving drivers lots of options for different tasks.

Under the hood, the KL24R has a Kubota D1503 engine. This 3-cylinder diesel engine is liquid-cooled and naturally aspirated. It has a below-average displacement of 91.5 cubic inches but runs at a very high 2700 rpm. The engine produces 23.6 horsepower, which is on the lower end for tractors. It has standard agricultural tires and a category I hitch for attaching tools. The tractor comes with a ROPS (Roll-Over Protective Structure) for safety and uses an electric starter for easy operation.
Show more...

Key Specifications

Category: Utility

Power Output: 24 hp (17.6 kW)

Transmission: Power shift

Drive Type: 4WD

Fuel Type: Diesel

Kubota KL24R vs. Similar Tractors

Power Output

The Power Output for the Kubota KL24R is Below Average. It is greater than 14% of similar Utility tractors in our database.

Horsepower distribution of Utility tractors

(across 4.7K+ tractors in our database)

Engine Displacement

The Engine Displacement for the Kubota KL24R is Below Average. It is greater than 22% of similar Utility tractors in our database.

Engine displacement distribution of Utility tractors

(across 1K+ tractors in our database)

Engine Rated RPM

The Engine Rated RPM for the Kubota KL24R is Above Average. It is greater than 90% of similar Utility tractors in our database.

Engine rated RPM distribution of Utility tractors

(across 1K+ tractors in our database)

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1503
Cooling Type
Liquid-cooled
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement
92 ci (1.5 L)
Bore
3.27 in (83.1 mm)
Stroke
3.64 in (92.5 mm)
Rated RPM
2700
Power Output
24 hp (17.6 kW)

Transmission

Type
Power shift
Forward Gears
16
Reverse Gears
16

Drivetrain

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
