Kubota KL23

Last Updated: June 2024

Overview

The Kubota KL23 is a compact utility tractor that was manufactured by Kubota between 1999 and 2005. It is equipped with a Kubota D1463, 22.7 horsepower diesel engine with a displacement of 89.3 cubic inches, operating at a rated RPM of 2500. The tractor features a 4x4 MFWD 4WD chassis, providing robust traction for various agricultural tasks. This model comes with power steering and a transmission with at least 24 forward and 16 reverse gears, enabling a versatile range of speeds and maneuverability. The tractor was sold with standard agricultural tires and was available with either a ROPS or a cab configuration, with corresponding operating weights of 2840 and 2877 pounds, respectively. Overall dimensions for the cab version are 118.7 inches in length, 49 inches in width, and 77.6 inches in height.
Show more...

Key Specifications

Category: Utility

Power Output: 22.7

Drive Type: 4WD

Operating Weight: Cab: 2877

Fuel Type: Diesel

Kubota KL23 vs. Similar Tractors

Power Output
Below Average
Greater than 13% of similar tractors.
Operating Weight
Below Average
Greater than 24% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1463
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
89.3
Bore (in)
3.23
Stroke (in)
3.64
Rated RPM
2500
Power Output (hp)
22.7

Transmission

Type
-
Forward Gears
24
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
Cab: 118.7
Width (in)
49
Height (in)
Cab: 77.6
Operating Weight (lb)
Cab: 2877

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
2005
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
