Kubota KL225

Last Updated: June 2024

Overview

The Kubota KL225 is a compact utility tractor, ideal for a variety of tasks thanks to its 4x4 MFWD 4WD configuration, providing stability and traction across different types of terrain. Power steering ensures easy maneuverability, while the 16-speed transmission, equal for both forward and reverse, enhances operational efficiency. The tractor is powered by a robust Kubota D1503 diesel engine which delivers 21.7 horsepower with a displacement of 91.5 cubic inches. This three-cylinder liquid-cooled engine is capable of handling demanding jobs without overheating. Offered with both ROPS and cab configurations, the KL225 ensures safety and comfort. The operating weight varies, with the ROPS version at 2480 pounds and the cab version at 2976 pounds. This machine was manufactured between 2008 and 2009, featuring a Category I hitch system. Its design focused on functionality and reliability without compromising on the compact dimensions ideal for a variety of agricultural settings.
Show more...

Key Specifications

Category: Utility

Power Output: 21.7

Drive Type: 4WD

Operating Weight: With ROPS: 2480, With Cab: 2976

Fuel Type: Diesel

Kubota KL225 vs. Similar Tractors

Power Output
Below Average
Greater than 12% of similar tractors.
Operating Weight
Below Average
Greater than 19% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1503
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
91.5
Bore (in)
3.27
Stroke (in)
3.64
Rated RPM
2600
Power Output (hp)
21.7

Transmission

Type
-
Forward Gears
16
Reverse Gears
16
Total Gears
24

Dimensions

Length (in)
With ROPS: 116.7, With Cab: 118.7
Width (in)
49
Height (in)
With ROPS: 77, With Cab: 79.5
Operating Weight (lb)
With ROPS: 2480, With Cab: 2976

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
22
Rear Tire Width (in)
9.5
Front/Rear Rim Diameter (in)
Front: Unknown, Rear: Unknown
Tire Type
Agricultural
Manufacture - End Year
2009
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
