Kubota KB18

Last Updated: June 2024

Overview

The Kubota KB18 is a sub-compact utility tractor that was manufactured between 2005 and 2007. This model comes equipped with a Kubota D1005 3-cylinder diesel engine that puts out 17.7 horsepower and operates at a rated RPM of 2600. The tractor features a 4WD chassis (4x4 MFWD 4WD) and is known for its GlideShift power shift transmission with 36 forward and 24 reverse gears. Despite the ample power in a compact frame, the KB18 boasts a liquid cooling system to manage its engine's thermal performance. Measuring 92.3 inches in length and 42.3 inches in width, with a height of 74.8 inches with ROPS, this tractor blends maneuverability with functionality, ensuring suitability for various tasks on smaller agricultural properties. With standard agricultural tires, it maintains a grounded traction profile suitable for its sub-compact classification. The operating weight of the tractor varies slightly, falling between 1532 to 1587 pounds, which suggests robust construction for its size.
Show more...

Key Specifications

Category: Utility, Sub-Compact

Power Output: 17.7

Transmission: Power shift

Drive Type: 4WD

Operating Weight: 1532 to 1587

Fuel Type: Diesel

Kubota KB18 vs. Similar Tractors

Power Output
Poor
Greater than 6% of similar tractors.
Operating Weight
Above Average
Greater than 81% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1005
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
-
Cylinders
3
Displacement (ci)
61.1
Bore (in)
2.99
Stroke (in)
2.9
Rated RPM
2600
Power Output (hp)
17.7

Transmission

Type
Power shift
Forward Gears
36
Reverse Gears
24
Total Gears
36 forward and 24 reverse

Dimensions

Length (in)
92.3
Width (in)
42.3
Height (in)
74.8
Operating Weight (lb)
1532 to 1587

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag) Front: 6.00-12, Rear: 8.3-22
Manufacture - End Year
2007
Hitch Type
-
Hitch Category
-
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
