Kubota JB17X

Last Updated: June 2024

Overview

The Kubota JB17X is a sub-compact utility tractor built to offer a versatile and agile solution for a variety of tasks. With a sturdy 4x4 MFWD chassis and power steering, it affords drivers with precise control and maneuverability. It employs a robust Kubota D1005, 3-cylinder, liquid-cooled diesel engine with 61.1 ci displacement, providing 16.8 hp and rated for 2600 RPM. The tractor's 6-speed manual transmission facilitates adequate range for utilization in different working conditions with 6 forward gears and 2 reverse gears. The open operator station, along with a 12 volt electric starter system, underscores the utility tractor's straightforward and user-centric design philosophy. Measuring 80.5 inches in length, 38.2 inches in width, and 72.4 inches in height, the JB17X balances compact dimensions with a solid 1268 lbs operating weight for stability. A ground clearance of 11.2 inches allows for good operational capability over varied terrain. Manufactured from 2009 to 2019, this tractor emerges as a reliable piece of machinery well-suited for small-scale farming, landscaping, and property maintenance tasks.
Show more...

Key Specifications

Category: Utility, Sub-Compact

Power Output: 16.8

Transmission: Manual

Drive Type: 4WD

Operating Weight: 1268

Fuel Type: Diesel

Kubota JB17X vs. Similar Tractors

Power Output
Poor
Greater than 5% of similar tractors.
Operating Weight
Poor
Greater than 9% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1005
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
3
Displacement (ci)
61.1
Bore (in)
2.99
Stroke (in)
2.9
Rated RPM
2600
Power Output (hp)
16.8

Transmission

Type
Manual
Forward Gears
6
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
80.5
Width (in)
38.2
Height (in)
72.4
Operating Weight (lb)
1268

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
12
Front Tire Width (in)
5
Rear Tire Diameter (in)
18
Rear Tire Width (in)
8
Front/Rear Rim Diameter (in)
-
Tire Type
Ag
Manufacture - End Year
2019
Hitch Type
-
Hitch Category
Category 0
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
Open
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
