Kubota GL368

Last Updated: June 2024

Overview

The Kubota GL368 is a compact utility tractor produced between 1993 and 1995. It features a Kubota V1903 four-cylinder diesel engine with a liquid-cooling system and a displacement of 113.3 cubic inches, capable of delivering 35.5 horsepower and operating at 2600 rated RPM. The tractor offers a four-wheel drive (4WD) chassis with power steering for improved maneuverability and a gear transmission with power shift, boasting 16 forward and reverse gears. The GL368 provides a choice between a ROPS or cab operator station, with a respective height of 85.6 and 90.2 inches. The length and width of this tractor are 130.9 inches and 59.1 inches respectively, with the operating weight ranging from 3197 lbs for the ROPS version to 3616 lbs for the cabbed model. The tractor rides on standard agricultural tires, with rear tire specs being 12.4-28. It was designed to tackle a variety of tasks in a compact package, suitable for smaller-scale farming, landscaping, and utility jobs. The GL368 includes a rear hitch with a Category I type, although its lift capacity is unknown.
Show more...

Key Specifications

Category: Utility

Power Output: 35.5

Transmission: Gear with Power Shift

Drive Type: 4WD

Operating Weight: 3616 (cab), 3197 (ROPS)

Fuel Type: Diesel

Kubota GL368 vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Average
Greater than 31% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
V1903
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally Aspirated
Cylinders
4
Displacement (ci)
113.3
Bore (in)
3.1
Stroke (in)
3.6
Rated RPM
2600
Power Output (hp)
35.5

Transmission

Type
Gear with Power Shift
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
130.9
Width (in)
59.1
Height (in)
90.2 (cab), 85.6 (ROPS)
Operating Weight (lb)
3616 (cab), 3197 (ROPS)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
28
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
Standard (ag)
Manufacture - End Year
1995
Hitch Type
Category I
Hitch Category
Category 3
Hitch Position
Rear
Hitch Capacity (lb)
-
Operator Station Type
ROPS or Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
