Kubota GL-350

Last Updated: June 2024

Overview

The Kubota GL-350 is a compact utility tractor that was manufactured from 1995 to 1998. This model was particularly noted for its robustness, sporting a powerful Kubota D1503-T turbocharged diesel engine with a displacement of 91.5 cubic inches capable of outputting 35 horsepower. It has a 4x4 MFWD 4WD chassis configuration, indicating a four-wheel drive mechanism, which is beneficial for various agricultural tasks and handling challenging terrain. With a power steering feature, the tractor ensures easier maneuverability. The Kubota GL-350 has a manual transmission offering 16 forward and reverse gears, which adapt to a range of different farming needs. It comes with agricultural tires standard, a category JIS1 hitch, and varied cabin options which include a Roll-Over Protection Structure (ROPS) and full cab, matching modern safety standards. The tractor's weight varies between 3472 and 3770 pounds depending on the presence of a cab or ROPS, and it features an upright height of 78 inches and practical dimensions that provide good clearance and stability for various agricultural operations.
Show more...

Key Specifications

Category: Utility

Power Output: 35

Transmission: Manual

Drive Type: 4WD

Operating Weight: 3472 (measured with ROPS), 3770 (measured with cab)

Fuel Type: Diesel

Kubota GL-350 vs. Similar Tractors

Power Output
Average
Greater than 32% of similar tractors.
Operating Weight
Below Average
Greater than 30% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
D1503-T
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Turbocharged
Cylinders
3
Displacement (ci)
91.5
Bore (in)
3.268
Stroke (in)
3.638
Rated RPM
2700
Power Output (hp)
35

Transmission

Type
Manual
Forward Gears
16
Reverse Gears
16
Total Gears
-

Dimensions

Length (in)
137.6
Width (in)
57.5
Height (in)
78 (measured with ROPS)
Operating Weight (lb)
3472 (measured with ROPS), 3770 (measured with cab)

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
4x4 MFWD 4WD
Drive Type
4WD
Steering Type
Power
Coolant Capacity (qts)
-
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
28
Rear Tire Width (in)
12.4
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
1998
Hitch Type
-
Hitch Category
JIS1
Hitch Position
-
Hitch Capacity (lb)
-
Operator Station Type
ROPS/Cab
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
