Kubota BX23S

Last Updated: June 2024

Overview

The Kubota BX23S is a 4WD backhoe loader tractor from the BX80 series, manufactured by Kubota since 2017. It is equipped with a Kubota D902 engine, which is a 0.9 L, 898 cm3, (54.8 cu·in) three-cylinder naturally aspirated diesel engine producing 23 HP at 3,200 rpm. The tractor features hydrostatic steering, wet disc brakes, and an open operator station with Rollover Protection Structure (ROPS). It has a fuel capacity of 25.0 liters (6.6 US gal; 5.5 Imp. gal) and an operating weight of 725 kg (1598.3 lbs). Designed to offer durability and versatility, the Kubota BX23S is appropriate for various tasks.

Key Specifications

Category: Specialized, Backhoe Loader

Power Output: 23

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 1598.3

Fuel Type: Diesel

Image Gallery

Kubota BX23S Tractor

Kubota BX23S vs. Similar Tractors

Power Output

Below Average

Greater than 16% of similar tractors.

Hitch Capacity

Average

Greater than 60% of similar tractors.

Operating Weight

Average

Greater than 41% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: D902
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 54.8
Bore (in): 2.83
Stroke (in): 2.9
Rated RPM: 3200
Power Output (hp): 23

Transmission

Type: Hydrostatic
Forward Gears: 2
Reverse Gears: 2
Total Gears: -

Dimensions

Length (in): 99
Width (in): 45.1
Height (in): 86.2
Operating Weight (lb): 1598.3

Power Take-Off (PTO)

PTO Type: -
PTO Speed 1 (rpm): -
PTO Speed 2 (rpm): -
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Hydrostatic
Coolant Capacity (qts): 3.28
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Turf/Bar/Industrial
Manufacture - End Year: -
Hitch Type: -
Hitch Category: I
Hitch Position: -
Hitch Capacity (lb): 1210
Operator Station Type: Open operator station with ROPS
Starter Type: Electric
Brake Type: Wet disc
Hydraulic System Type: -
