Kubota B7610

Last Updated: June 2024

Overview

The Kubota B7610 is a 4WD compact utility tractor from the B7x10 series. This tractor was manufactured by the Kubota from 2004 to 2007. The Kubota B7610 is equipped with a 1.1 L three-cylinder diesel engine and hydrostatic transmission with infinite (2-range) forward and reverse gears. The tractor is equipped with power steering, wet disc type brakes, open operator station with two-post ROPS (rollover protection structure), and a 20.0 liters (5.3 US gal.; 4.4 Imp. gal) fuel tank. It has a three-point hitch system with a Category I rating and a lift capacity of 1,356 lbs. The tractor is also fitted with a Kubota D1105-E-D16 engine that produces 24 horsepower and operates at 2600 rated RPM.

Key Specifications

Category: Utility

Power Output: 24

Transmission: Hydrostatic

Drive Type: 4WD

Operating Weight: 1367

Fuel Type: Diesel

Image Gallery

Kubota B7610 Tractor

Kubota B7610 vs. Similar Tractors

Power Output

Below Average

Greater than 16% of similar tractors.

Hitch Capacity

Poor

Greater than 1% of similar tractors.

Operating Weight

Poor

Greater than 10% of similar tractors.

Technical Specifications

Engine

Manufacturer: Kubota
Model: D1105-E-D16
Cooling Type: Liquid-cooled
Cylinder Orientation: Inline
Valve Configuration: -
Fuel Type: Diesel
Induction Type: Natural aspirated
Cylinders: 3
Displacement (ci): 68.5
Bore (in): 3.071
Stroke (in): 3.087
Rated RPM: 2600
Power Output (hp): 24

Transmission

Type: Hydrostatic
Forward Gears: Infinite (2-range)
Reverse Gears: Infinite (2-range)
Total Gears: -

Dimensions

Length (in): 91.3
Width (in): 46.1
Height (in): 77.2
Operating Weight (lb): 1367

Power Take-Off (PTO)

PTO Type: Independent
PTO Speed 1 (rpm): 540
PTO Speed 2 (rpm): 960
PTO Speed 3 (rpm): -

Miscellaneous

Chassis: 4x4 MFWD 4WD
Drive Type: 4WD
Steering Type: Power
Coolant Capacity (qts): 4
Front Tire Diameter (in): -
Front Tire Width (in): -
Rear Tire Diameter (in): -
Rear Tire Width (in): -
Front/Rear Rim Diameter (in): -
Tire Type: Ag
Manufacture - End Year: 2007
Hitch Type: Three-Point Hitch
Hitch Category: I
Hitch Position: Rear
Hitch Capacity (lb): 1,356 lbs
Operator Station Type: Open operator station with two-post ROPS
Starter Type: Electric
Brake Type: Wet disc type
Hydraulic System Type: Open center
