Kubota B7410DT

Last Updated: June 2024

Overview

The Kubota B7410DT is an efficient tractor powered by a 3-cylinder Kubota D782-E-D20 diesel engine that delivers a power output of 18 hp. With a liquid cooling system that has a capacity of approximately 3.2 quarts, the tractor maintains optimal engine temperature. The transmission is geared, with 6 forward gears and 2 reverse, facilitating a variety of speeds suitable for different tasks. With a PTO power of 15 hp measured at 2900 rpm, the B7410DT is capable of handling a range of implements. The operating weight of the tractor is 1245.7 pounds, which combined with its compact frame, offers a solid balance of maneuverability and stability for multiple agricultural tasks. The three-point hitch supports a Category I setup with a lift capacity of 1058.3 pounds, which provides strength and versatility for attaching various tools and implements. It's worth noting its compact size, with a projected length of 91.2 inches and a width of 43.2 inches, allowing it to access tight spaces easily.
Show more...

Key Specifications

Power Output: 18

Transmission: Gear

Operating Weight: 1245.7

Fuel Type: Diesel

Lift Capacity: 1058.3

Technical Specifications

Engine

Manufacturer
Kubota
Model
D782-E-D20
Cooling Type
Liquid-cooled
Cylinder Orientation
-
Valve Configuration
-
Fuel Type
Diesel
Induction Type
E-TVCS
Cylinders
3
Displacement (ci)
47.5
Bore (in)
-
Stroke (in)
-
Rated RPM
2900
Power Output (hp)
18

Transmission

Type
Gear
Forward Gears
6
Reverse Gears
2
Total Gears
-

Dimensions

Length (in)
91.2 (calculated from 7.6 ft assuming there's an error in the original data assuming inches, as 7.6 inches is not plausible for length)
Width (in)
43.2 (calculated from 3.6 ft)
Height (in)
-
Operating Weight (lb)
1245.7

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
-
PTO Speed 2 (rpm)
-
PTO Speed 3 (rpm)
-

Miscellaneous

Chassis
-
Drive Type
-
Steering Type
-
Coolant Capacity (qts)
3.2 (calculated from 0.8 gallons)
Front Tire Diameter (in)
-
Front Tire Width (in)
-
Rear Tire Diameter (in)
-
Rear Tire Width (in)
-
Front/Rear Rim Diameter (in)
-
Tire Type
-
Manufacture - End Year
-
Hitch Type
Cat. I
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
1058.3
Operator Station Type
-
Starter Type
-
Brake Type
-
Hydraulic System Type
-
