Kubota B7000

Last Updated: June 2024

Overview

The Kubota B7000 is a versatile sub-compact utility tractor that was produced by Kubota from 1973 to 1977. Available in both 2WD (B7000E) and 4WD (B7000D) configurations, it is designed to serve the needs of small-scale farming and landscaping tasks. The B7000 is powered by a robust Kubota Z650 engine, a two-cylinder diesel that offers 14 horsepower and a displacement of 39.1 cubic inches. Operating at a rated 3000 RPM, the liquid-cooled engine ensures reliable performance across a variety of applications.

This model features a 6-speed unsynchronized gear transmission with 6 forward and 2 reverse gears, providing a range of speeds to tackle different tasks. The manual steering system and open operator station are indicative of its era, prioritizing straightforward mechanics and ease of maintenance. The tractor rides on agricultural tires, with a 5.00-12 front and 8-16 rear configuration, supporting its operational weight of 1050 lbs.

The Kubota B7000 has a modest footprint, measuring 78.4 inches in length, 35.4 inches in width, and 45.7 inches in height, with a wheelbase of 48.4 inches. This compact size, coupled with a rear hitch lift capacity of 1103 lbs, makes it an efficient tool for a variety of tasks, from plowing to hauling. Despite the absence of modern comforts, the B7000's durability and ease of use have cemented its reputation as a reliable workhorse in the tractor community.

In summary, the Kubota B7000 is a testament to practical design and enduring utility. Its straightforward engineering and durable construction have enabled it to remain a valuable asset for small-scale agricultural operations, even several decades after production ceased.
Show more...

Key Specifications

Category: Utility, Sub-Compact

Power Output: 14.0

Transmission: Non-synchronized Gear

Drive Type: 2WD, 4WD

Operating Weight: 1,050

Fuel Type: Diesel

Kubota B7000 vs. Similar Tractors

Power Output
Poor
Greater than 2% of similar tractors.
Hitch Capacity
Below Average
Greater than 20% of similar tractors.
Operating Weight
Poor
Greater than 0% of similar tractors.

Technical Specifications

Engine

Manufacturer
Kubota
Model
Z650
Cooling Type
Liquid-cooled
Cylinder Orientation
Inline
Valve Configuration
-
Fuel Type
Diesel
Induction Type
Naturally aspirated
Cylinders
2
Displacement (ci)
39.1
Bore (in)
-
Stroke (in)
-
Rated RPM
3000
Power Output (hp)
14.0

Transmission

Type
Non-synchronized Gear
Forward Gears
6
Reverse Gears
2
Total Gears
8

Dimensions

Length (in)
78.4
Width (in)
354.0
Height (in)
45.7
Operating Weight (lb)
1,050

Power Take-Off (PTO)

PTO Type
-
PTO Speed 1 (rpm)
540
PTO Speed 2 (rpm)
860
PTO Speed 3 (rpm)
1,000

Miscellaneous

Chassis
4x2 2WD, 4x4 MFWD 4WD
Drive Type
2WD, 4WD
Steering Type
Manual
Coolant Capacity (qts)
-
Front Tire Diameter (in)
5.0
Front Tire Width (in)
12.0
Rear Tire Diameter (in)
8
Rear Tire Width (in)
16.0
Front/Rear Rim Diameter (in)
-
Tire Type
Agricultural
Manufacture - End Year
1977
Hitch Type
Three-Point Hitch
Hitch Category
Category 1
Hitch Position
Rear
Hitch Capacity (lb)
1103
Operator Station Type
Open
Starter Type
Electric
Brake Type
-
Hydraulic System Type
-
